Design Improvement on Shipping Container Spraying Production Line

Abstract:

This paper describes the design of a flip-frame mechanism for shipping container spray painting production line. The idea of the flip-frame mechanism is to reduce, to a large extent, paint wastage during spray painting of the quadrangular exterior surfaces of the shipping container. Clamping of the shipping container on the flip-frame is achieved by hydraulic cylinders. A roller chain and a sprocket is used to drive the flip-frame because of their simplicity, strength, ability to work under harsh condition and require little lubrication.

• Periodical: Advanced Materials Research (Volumes 989-994)
• Pages: 2890-2894
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.989-994.2890
• Online since: July 2014
• Authors: Sunday Onyedikachi Okorie*, Jing Shi
• Keywords: Chain Drive, Flip-Frame, Hydraulic Cylinder Clamping, Mechanism, Sprocket

References

[1] James C . Conwell and G. E Johnson. Experimental Investigation of chain tension and roller sprocket impact forces in chain drives.

DOI: 10.1016/0094-114x(95)00070-f

[2] Sohail Anjum, Nabeel Kamal, Umar Shahbaz Khan, Javaid Iqbal, Umar Izhar, Nasir Rasheed, M.A. Khan. (2012).

[3] Nancy G. Leveson, (2002). System Safety Engineering: Back To The Future. Aeronautics and Astronautics. Massachusetts Institute of Technology.

[4] Roland Bizolier, (1992).

[5] Prasad N. Atkar, Uniform Coverage of Simple Surfaces Embedded in R3 for Auto-Body Painting, Carnegie Mellon University, Pittsburgh PA 15213, USA.
