Research for Guide Groove Configuration of Rotary Valve

Abstract:

Rotary valve is a device to achieve fast commutation hydraulic transmission . Rotary valve is driven by a hydraulic motor drive and can achieve rapid conversion of the hydraulic circuit . Rotary valve spool by a rotating shaft , housing , shafts and bearings and other components. Guide grooves machined on the spool shaft is evenly distributed for hydraulic cylinder into the oil and return oil conversion. The coordinate gap between the spool shaft and valve chamber bore Because will affect the leakage in the leak. How to improve the guide groove structure We can put the guide groove by high and low partition instead of overlapping arrangement. Reducing leakage within the valve chamber and Meet with the requirements of the spool shaft and valve chamber bore.

• Periodical: Advanced Materials Research (Volumes 989-994)
• Pages: 2874-2877
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.989-994.2874
• Online since: July 2014
• Authors: Su Ying Xu*
• Keywords: Coordinate Gap, Guide Groove, Leaks, Rotary Valve, Spool Shaft

References

[1] Qiu Lijun . Research on new rotary valve hydraulic shaker . Graduate thesis . 1992. 4.

[2] Wang Jiwei, Zhang Hongjia , Huang Yi 《hydraulic and pneumatic drive》 . Machinery Industry Press , 2012. 6. pp.8-56.

[3] Yang Naiqiao, hydraulic transmission oil situation and development [ J ] . Hydraulic and pneumatic seals , 2004, ( 5 ).

[4] Yang Jia, Qiu Lijun, 2011 2nd International Conference on Mechanic Automation and Control Engnieering, MACE2011-Proceedings, pp.325-328.

[5] Qiu Lijun, Yang Jia, Advanced Materials Research, V 322, pp.497-500. (2012).
