Design of Underground Gas Concentration and Humidity Monitoring System Based on RS-485

Abstract:

In order to achieve long distance monitoring of gas concentration and humidity underground coal mine,a new monitor of gas concentration and humidity,which contains upper computer,master station and a lot of monitoring points,is designed.Every monitoring point is consisted of gas concentration sensor MJC4/3.0L and humidity sensor HS1101,which is used to conveys the data to master station by RS-485,again by RS-485 transmitted to the upper computer and it realizes the real-time monitoring of gas concentration and humidity undereground coal mine.

• Periodical: Advanced Materials Research (Volumes 989-994)
• Pages: 2962-2964
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.989-994.2962
• Online since: July 2014
• Authors: Yue Hong Long*
• Keywords: HS1101, Humidity Underground Coal Mine, MJC4/3.0L, Monitoring of Gas Concentration, RS-232, RS-485, Upper Computer

References

[1] Feng Lei. Coal mine gas concentration monitoring and alarm system. [D] master's degree thesis, xi an university of electronic science and technology, xi , an, (2010).

[2] Mao Deping, Lin Youzhu. A system of temperature and humidity measurement and control based on RS485. [J]The modern electronic technology2007(02).

[3] Wu Xingzhong OuQingLi. A design of PC and single chip machine RS232 serial port communication[J]. Journal of electronic measurement technology abroad. 2009 (01).

[4] Chen Liang. A design of a monitoring system of coal mine gas sensor hardware [J]. Journal of information science and technology. 2009 (16).

[5] Liu Pinzhen. Selection methods of humidity sensor[J]. Journal of monitoring instrumentation and analysis. 1990 (02).

[6] Hu Yuliang, Dong Guanjun. Design of PC software based on 51 single chip microcomputer . [J]. Journal of shanxi metallurgy, 2009 (01).
