The Finite Element Analysis of the Large-Diameter Composite Slurry Valve Gate

Abstract:

In a long distance slurry pipeline transport system, pulp valve plays a vital role, which combined the pulp valve application is more, ram is one of the important components of composite slurry valve. This article mainly aims at gate has carried on the design and analysis, finite element modeling, and study the corresponding constraints, in the process of loading method, large diameter combination valve gate stress and strain distribution are obtained, combined with the optimization method and finite element analysis software for its structure optimization research, realize the lightweight of the gate. To reduces the manufacturing cost of the gate, as to provide theoretical basis for design.

• Periodical: Advanced Materials Research (Volumes 989-994)
• Pages: 3149-3152
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.989-994.3149
• Online since: July 2014
• Authors: Jie Wu*, Zhao Meng Yang, Dong Zheng Wang
• Keywords: Composite Slurry Valve Gate, Finite Element Analysis (FEA), Large-Diameter

References

[1] H. p. Xie，S. Zhang and Y. Yang: Annals of the PR, Vol. 30 (2008) No. 1, p.87.

[2] M.F. Spotts: Design of Machune Elements (China machine press, China2002).

[3] ChristoPh M: Constraint-BasedComPuter-AidedDesig, Journal of Computing and InformationSeienceinEngineering, 2005, Volumes, Issue3, P182.

[4] S.J. Lee: Capitation detection of butterfly valve using support vector machines , Journal of sound and Vibration, 2005, P25.
