Sensorless Control of Switched Reluctance Motors Based on Pulse Injection, Position Sectors Divided and Variable Thresholds

Abstract:

To realize starting operation and reduce position estimation error of switched reluctance motor (SRM) without position sensor, a novel control method based on pulse injection, divided angle section and variable threshold is presented. The starting operation of SRM can be accomplished by injecting high frequency pulse and judging position sectors. Variable threshold is used to reduce position estimation error. The value of threshold is obtained by looking up table prestored in controller. The method avoids complicated mathematical model and is suitable for starting operation with two phases. Besides, rotor position estimation error of this method is analyzed and the method which can decreased the error is proposed. At last, the experiment has been done to verify the performance of the control method.

• Periodical: Advanced Materials Research (Volumes 989-994)
• Pages: 3252-3257
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.989-994.3252
• Online since: July 2014
• Authors: Zi Fei Jia*, De An Zhao, Yu Yan Zhao
• Keywords: Position Estimation Error, Sensorless Control, Switched Reluctance Motor, Variable Thresholds

References

[1] Qiu Yihui, Ma Zhiyuan and Zhan Qionghua, in: Start exploration of position sensorless SRM without rotor reversing[J]. Transactions of China Electro technical Society , 2001, 16(2): 18-22.

[2] Zhou Jingcheng, Wang Xiaolin, and Deng Zhiquan, in: The Position Sensorless Technolo gy of Switched Reluctance Motor Based on the Regional Comparison of Three-Phase Inductance[J]. Transactions of China Electro technical Society , 2012, 27(7): 34-40.

DOI: 10.1109/tpel.2011.2179065

[3] L. Shen, J. H. Wu, and S. Y. Yang, in: Initial position estimation in SRM using bootstrap circuit without predefined inductance parameters. IEEE Trans. Power Electron., vol. 26, no. 9, p.2449–2456, Sep. (2011).

DOI: 10.1109/tpel.2011.2107334

[4] Cai Jun and Deng Zhiquan Sensorless control of switched reluctance motor based on phase inductance model in linear regions[J] . Proceedings of the CSEE, 2012, 32(15) : 114-123.

DOI: 10.1109/tpel.2011.2179065

[5] Gao Hongwei, Salmasi F R and Ehsani M, in: Inductance model-based sensorless control of the switched reluctance motor drive at low speed[J]. IEEE Transactions on Power Electronics, 2004, 19(6): 1568-1573.

DOI: 10.1109/tpel.2004.836632

[6] Pasquesoone G, Mikail R and Husain I, in: Position estimation at starting and lower speed in three-phase switched reluctance machine using pulse injection and two thresholds[J]. IEEE Transactions on Industry Applications, 2011, 47(4): 1724-1731.

DOI: 10.1109/tia.2011.2156751
