Research on Preparation of Aluminum-Metal Coating and its Microstructure by Melting-Casting

Abstract:

A sort of Aluminum-metal coating, which is characterized by a bi-layered structure of Fe₂O₃+Cr₂O₃+Al plus NiO+Al layers, was successfully prepared on steel substrate by melting-casting technique. The microstructure, the bonding status of the interface between the coating and the substrate, and the element distribution of the coating were studied. The results indicate that, there is an excellent bonding between the coating and the substrate, and no hole and gap in the composite is found out. Moreover, there is obvious element diffusion in the interface. The coating is composed of block phase, columnar grain, and dendrites. In addition, the elements present a uniform distribution in the interface but an obvious segregation in the middle of the coating.

• Periodical: Advanced Materials Research (Volumes 989-994)
• Pages: 331-336
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.989-994.331
• Online since: July 2014
• Authors: Xiao Feng Xue*, Ze Hua Zhou, Ze Hua Wang, Jia Shao, Huan Long Yuan, Zhao Jun Zhong
• Keywords: Al₂O₃-Metal Coating, Element Distribution, Melting-Casting, Microstructure

References

[1] Toma D, Brandl W, Marginean G. Wear and corrosion behaviour of thermally sprayed cermet coatings [J]. Surface and Coatings Technology, 2001, 138(2): 149-158.

DOI: 10.1016/s0257-8972(00)01141-5

[2] Bergmann C P, Vicenzi J. Protection against erosive wear using thermal sprayed cermet: a review [M]. Springer Berlin Heidelberg, (2011).

DOI: 10.1007/978-3-642-21987-0_1

[3] Zhang J, Wang Z, Lin P, et al. Effect of Sealing Treatment on Corrosion Resistance of Plasma-Sprayed NiCrAl/Cr2O3-8 wt. % TiO2 Coating [J]. Journal of thermal spray technology, 2011, 20(3): 508-513.

DOI: 10.1007/s11666-010-9528-6

[4] Cliche G, Dallaire S. Synthesis and deposition of TiC-Fe coatings by plasma spraying [J]. Surface and Coatings Technology, 1991, 46(2): 199-206.

DOI: 10.1016/0257-8972(91)90162-p

[5] Sidhu T S, Prakash S, Agrawal R D. Studies of the metallurgical and mechanical properties of high velocity oxy-fuel sprayed stellite-6 coatings on Ni-and Fe-based superalloys [J]. Surface and Coatings Technology, 2006, 201(1): 273-281.

DOI: 10.1016/j.surfcoat.2005.11.108

[6] Saha G C, Khan T I, Zhang G A. Erosion–corrosion resistance of microcrystalline and near-nanocrystalline WC–17Co high velocity oxy-fuel thermal spray coatings [J]. Corrosion Science, 2011, 53(6): 2106-2114.

DOI: 10.1016/j.corsci.2011.02.028

[7] Li J, Yu Z, Wang H, et al. Microstructural characterization of titanium matrix composite coatings reinforced by in situ synthesized TiB+TiC fabricated on Ti6Al4V by laser cladding[J]. Rare Metals, 2010, 29(5): 465-472.

DOI: 10.1007/s12598-010-0151-y

[8] Guozhi X, Xiaolong S, Dongjie Z, et al. Microstructure and corrosion properties of thick WC composite coating formed by plasma cladding [J]. Applied Surface Science, 2010, 256(21): 6354-6358.

DOI: 10.1016/j.apsusc.2010.04.016

[9] Roos E, Naga S M, Richter R N, et al. Electron beam physical vapour deposition and mechanical properties of c-ZrO2-ZTA-coatings on alloy 617 substrates [J]. Ceramics International, 2012, 38(4): 3317-3326.

DOI: 10.1016/j.ceramint.2011.12.041

[10] Li J S, Zhang C R, Li B, et al. Boron nitride coatings by chemical vapor deposition from borazine [J]. Surface and Coatings Technology, 2011, 205(12): 3736-3741.

DOI: 10.1016/j.surfcoat.2011.01.032

[11] Varma A, Mukasyan A S. Combustion synthesis of advanced materials: Fundamentals and applications [J]. Korean Journal of Chemical Engineering, 2004, 21(2): 527-536.

DOI: 10.1007/bf02705444

[12] Mukasyan A S, White J D E. Combustion joining of refractory materials [J]. International Journal of Self-Propagating High-Temperature Synthesis, 2007, 16(3): 154-168.

DOI: 10.3103/s1061386207030089

[13] Morsi K. The diversity of combustion synthesis processing: a review [J]. Journal of Materials Science, 2012, 47(1): 68-92.

[14] La P, Bai M, Xue Q, et al. A study of Ni3Al coating on carbon steel surface via the SHS casting route [J]. Surface and Coatings Technology, 1999, 113(1): 44-51.

DOI: 10.1016/s0257-8972(98)00820-2

[15] Niu M, Bi Q, Kong L, et al. A study of Ni3Si-based composite coating fabricated by self-propagating high temperature synthesis casting route [J]. Surface and Coatings Technology, 2011, 205(17): 4249-4253.

DOI: 10.1016/j.surfcoat.2011.03.031

[16] Merzhanov A G. Fundamentals, achievements, and perspectives for development of solid-flame combustion [J]. Russian Chemical Bulletin, 1997, 46(1): 1-27.

DOI: 10.1007/bf02495340
