Study of Dislocation Densities of Thick GaN Films

Article Preview

Abstract:

The dislocation density of GaN thick films has been measured by high-resolution X-ray diffraction. The results show that both the edge dislocations and the screw dislocation reduce with increasing the GaN thickness. And the edge dislocations have a larger fraction of the total dislocation densities, and the densities for the edge dislocation with increasing thickness reduce less in contrast with those for the screw dislocation.
