Mathematical Simulation and Optimization of Structure and Performance of Air Way of Purging Plug in Ladle

Abstract:

The temperature and thermal stress of different air ways of purging plug were comparatively analyzed by means of finite element method. Combined with the physical properties of the air ways of purging plug, a set of field tests were carried out for the optimum structure. The results showed that the structure of air ways of purging plug had great impact on the thermal stress. In service process, the damage of the air way was mainly caused by tensile stress in axial direction. By evenly distributes the tensile stress in axial direction, the stress decreased by 40% compared with the original one, and thermal shock resistance of purging plug D with circular slit structure has been improved and also proved in the field test.

• Periodical: Advanced Materials Research (Volume 997)
• Pages: 565-569
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.997.565
• Online since: August 2014
• Authors: Wen Gang Yang, Guo Qi Liu, Feng Ling Yang, Tian Fei Ma
• Keywords: Air Way, Purging Plug, Thermal Stress

References

[1] Xu Xiaohai, Feng Gaishan. Refractory technical manuals[M]. Beijing: Metallurgical Industry Press, 2000: 661- 662.

[2] Yu Puliang. Thermal stress analysis of purging plug in ladle[D]. Hubei: Wuhan University of Science and Technology, (2009).

[3] Liu Huimin, Sun Jialin, Wang Jinxiang. Effect of gradient stress distribution of purging plug under blowing argon condition[J]. Journal of Wuhan University of Technology, 2010, 32(7): 8-11.

[4] Zhang Hui，Li Hongxia, Yang Bin, et al. Analysis of stress field distribution of purging plug in ladle under refining condition [J]. Refractories, 2009, 43 (2): 113-116.

[5] Yang Wengang, Liu Guoqi, Wang Jianguo, et al. The analysis of stress distribution of purging plug in ladle in the process of service[J]. Refractories, 2013, 47(2): 107-110.
