Composite Structure of UHPFRC and Normal Strength Concrete with Innovative Shear Connector

Abstract:

UHPC (“UHPC” will be used in the paper for UHPFRC with steel fibres) offers great potential in terms of extending the service life of structures and reducing material consumption in bridge construction. One way to achieve the economical application of UHPC is to mechanically connect optimized UHPC structures with other structural elements made of conventional materials into a single functional unit. This paper describes the development of a structural system that provides effective use of the properties of UHPC and conventional concrete. An innovative coupling element made of UHPC material was developed for the connection. During development, computational and experimental analyses were performed, including static and fatigue resistance tests of the coupling and full-scale load tests of a prototype bridge girder. The article briefly summarizes the individual parts of the research and presents its results.

• Periodical: Advances in Science and Technology (Volume 176)
• Pages: 39-45
• DOI: https://doi.org/10.4028/p-NimG2q
• Online since: May 2026
• Authors: Adam Čítek*, Jan Prchal, Jan Mourek, David Čítek, Jan Marek, Jiří Kolísko
• Keywords: Composite Structure, Experiment, NSC, UHPFRC

References

[1] S. Abbas, M. L. Nehdi, M. A. Saleem, Ultra-High Performance Concrete: Mechanical Performance, Durability, Sustainability and Implementation Challenges. International Journal of Concrete Structures and Materials, Springer Science and Business Media LLC (2016), pp.271-295

DOI: 10.1007/s40069-016-0157-4

[2] Z. Haber, I. De la Varga, Igor, B. Graybeal, Properties and Behavior of UHPC-Class Materials, Federal Highway Administration, Washington, D.C. (2018)

[3] J. Kolísko, P. Tej, D. Čítek, J. Mourek, J. Marek, J. Prchal, Shear connector strip and structural member with such shear connector strip. CZ Patent n.310325 B6, KŠ PREFA s.r.o. and Czech Technical University in Prague (2025).

[4] X. Li, J. He, Y. Zhou, F. Xu, T. Okazaki, H. Fang, A comprehensive review of shear connectors in demountable composite beams, Journal of Constructional Steel Research, Elsevier B.V., 218 (2024), p.108723

DOI: 10.1016/j.jcsr.2024.108723

[5] C. A. Benedetty, V. B. dos Santos, P. A. Krahl, A. Rossi, F. de Andrade Silva, D. C. T. Cardoso, C. H. Martins, Flexural and shear behavior of steel-UHPC composite beams: a review, Engineering Structures, Elsevier B.V., 293 (2023) p.116649

DOI: 10.1016/j.engstruct.2023.116649

[6] ČSN EN 1991-2 (2006): Eurocode 1: Actions on structures – Part 2: Traffic loads on bridges. European Committee for Standardization (CEN), Brussels, 2006. Czech Standards Institute, Prague, 2006.
