Time-Dependent Nonlinear Ferroelastic Behaviour of Soft Lead Zirconate Titanate Piezoceramics

Abstract:

Motivated by predicting the performance and reliability of piezoelectric devices, considerable research efforts have been made in recent years to mathematically describe the largesignal nonlinear behaviour of ferroelectric piezoceramics. The success of such modelling approach depends strongly on our knowledge of the loading history dependence of the material properties. In this experimental work, the nonlinear ferroelastic behaviour was investigated in detail for a commercially available soft lead zirconate titanate (PZT) material under low-frequency compressive stress loading. It was found that the strain response was significantly loading rate dependent. The evolution of the elastic moduli was determined using fast small-stress partial unloading method, which was specially designed to minimize the time-dependent effect as much as possible. The results were used to separate the reversible elastic deformation from the irreversible plastic strain due to domain switching.

• Periodical: Advances in Science and Technology (Volume 45)
• Pages: 2464-2471
• DOI: https://doi.org/10.4028/www.scientific.net/AST.45.2464
• Online since: October 2006
• Authors: Da Yu Zhou, Marc Kamlah, Yi Xiang Gan, Bernd Laskewitz
• Keywords: Domain Switching, Elastic Compliance, Piezoceramic, Plastic Strain, Stress Strain

References

[1] C. Schuh, Th. Steinkopff, A. Wolff, and K. Lubitz, Proceedings of SPIE, Vol. 3992 (2000) 165-175.

[2] R. Müller-Fiedler and V. Knoblauch, Microelectron. Reliab., 43 (2003) 1085-1097.

[3] M. Kamlah, Continuum Mech Thermodyn., 13 (2001) 219-268.

[4] C. M. Landis, Curr. Opin. Solid St. M., 8 (2004) 59-69.

[5] IEEE Standard on Piezoelectricity, ANSI/IEEE Std. 176-1987. IEEE, New York, NY10017, (1988).

[6] H. Cao and A. G. Evans, J. Am. Ceram. Soc., 76 (1993) 890-896.

[7] A.B. Schäufele and K. H. Härdtl, J. Am. Ceram. Soc., 79 (1996) 2637-2640.

[8] D.Y. Zhou, M. Kamlah, and D. Munz, J. Eur. Ceram. Soc., 25 (2005) 425-432.

[9] D.Y. Zhou, M. Kamlah, and D. Munz, J. Am. Ceram. Soc., 88 (2005) 867-874.

[10] T. Fett, D. Munz, and G. Thun, Ferroelectrcis, 274 (2002) 67-81.

[11] M. Selten, G.A. Schneider, V. Knoblauch, and R.M. McMeeking, Int. J. Solids Struct., 42 (2005) 3953-3966.

[12] D.Y. Zhou and M. Kamlah, Acta Mater., 54 (2006) 1389-1396.

[13] S. Stotz, Ferroelectrics, 76 (1987) 123-132.

[14] M.R. Soares, A. M. R. Senos, and P. Q. Mantas, J. Eur. Ceram. Soc., 20 (2000) 321-334.

[15] D.Y. Zhou, Experimental Investigation of Nonlinear Constitutive Behaviour of PZT Piezoceramics. PhD Thesis, University of Karlsruhe (TH), published as research report of Forschungszentrum Karlsruhe, FZKA 6869, (2003).
