Magnetoelectric Coupling in Multi-Ferro Fe-Pd/PZT/Fe-Pd Laminate Composites

Abstract:

Magnetoelectric(ME) coupling in multi-ferroic composite designed by using two material elements of Pb(Zr, Ti)O3 (PZT: 260μm) and magnetostrictive alloys(Galfenol based Fe-Ga-X(X=Al, Co), ferromagnetic shape memory Fe-Pd) was investigated. Output ME Voltage under the driving a.c.magnetic field Hac at f = 1 Hz in Fe81Ga19/PZT/ Fe81Ga19, Fe80Ga15Al5 /PZT/ Fe80Ga15Al5, Fe76Ga17Co7/PZT/ Fe76Ga17Co7 composites, in which the magnetostrictive foils(50μm thickness) were prepared by rapid solidification, increased in proportion to the actuated force than the magnetostriction.Moreover，output ME Voltage in Fe70Pd30 / PZT/ Fe70Pd30 laminates, in which the Fe70Pd30 films (10μm thickness) on PZT were deposited by sputtering method, exhibited 8 V at Hac of 175Oe, which is larger than 7.16 V for Fe76Ga17Co7 (50μm)/PZT/ Fe76Ga17Co7 (50μm) composites

You might also be interested in these eBooks

12th INTERNATIONAL CERAMICS CONGRESS PART F

View Preview

Info:

Periodical:

Advances in Science and Technology (Volume 67)

Pages:

98-103

DOI:

https://doi.org/10.4028/www.scientific.net/AST.67.98

Citation:

Cite this paper

Online since:

October 2010

Authors:

Teiko Okazaki, Yasubumi Furuya, Yusuke Sado, Yoshiyuki Hayashi, Syunsuke Sato, Chihiro Saito

Keywords:

Fe-Ga-X(X=Al, Co) Foil, Fe-Pd Thin Film, Ferroelectric Composite, Ferromagnetic Composite, Magnetic Sensor, Magnetoelectric Effect, Pb(Zr,Ti)O₃

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] T. H. O'Dell. Electron. Power, 11 (1965) 266.

Google Scholar

[2] L. P. M. Bracke and R. G. van Vliet, Int. J. Electron, 51 (1981) 255.

Google Scholar

[3] J. Ryu, A. V. Carazo, K. Uchino, and H. Kim, Jpn. J. Appl. Phys., Part 1 40 (2001) 4948.

Google Scholar

[4] K. Mori and M. Wuttig, Appl. Phys. Lett. 81 (2002) 100.

Google Scholar

[5] M. I. Bichurin, D. A. Filippov, V. M. Petrov, V. M. Laletsin, N. Paddubunaya, and G. Srinivasan, Phys. Rev. B68 (2003) 132408.

Google Scholar

[6] X. Dong, J. Zhai, F. Bai, J. F. Li, and D. Viehland, Appl. Phys. 97 (2005) 103902.

Google Scholar

[7] D. A. Filippov, U. Laletsin, and G. Srinivasan, Appl. Phys. 102 (2007) 093901.

Google Scholar

[8] R. D. James and M. Wuttig, Philos. Mag. A77 (1998) 1273.

Google Scholar

[9] T. Kubota, T. Okazaki, and Y. Furuya, J. Mag. Mag. Mater. 239 (2002) 551.

Google Scholar

[10] T. Okazaki, M. Tanaka, N. Ogasahara, Y. Furuya, C. Saito and N. Imaizumi: Development of Magnetic-Field-Driven Micro-Gas Valve, Mater. Trans. 50 (2009) 461-466.

DOI: 10.2320/matertrans.mbw200805

Google Scholar
