Synthesis of Crystallized TiNi Films by Ion Irradiation

Abstract:

TiNi is well known as a typical shape-memory alloy, and is expected to be a promising material for micro actuators. In order to realize micro electro mechanical systems (MEMS) with this material, we have to get thin crystal film of the material, since the shape-memory property appears only when the structure is crystalline. In our previous studies we developed a new apparatus as well as a new deposition process for lowering the crystallization temperature by using ion irradiation. In addition, we have found that the deposited film by the process can be crystallized at very low temperature (below 473 K) without annealing but with simultaneous irradiation of Ar ions during sputter-deposition. In this study, we aim for the realization of crystallized TiNi film, which is deposited on Si substrate below 373 K substrate temperature. In order to realization the purpose, we have revealed the effect of Ar ion energy on lowering the crystallization temperature. The ion energy is measured with a quadrupole mass spectrometer (QMS) having an ion energy analyzer. The deposited TiNi films are examined with an X-ray diffraction (XRD). We found the plasma potential against the reactor chamber is important to be considered in the ion irradiation energy. The effects of ion energy for the crystallization of TiNi film are discussed.

• Periodical: Advances in Science and Technology (Volume 78)
• Pages: 87-91
• DOI: https://doi.org/10.4028/www.scientific.net/AST.78.87
• Online since: September 2012
• Authors: Noriaki Ikenaga, Yoichi Kishi, Zenjiro Yajima, Noriyuki Sakudo
• Keywords: Ion Energy, Ion Irradiation, Low Temperature Crystallization, Multi-Sputtering, Plasma Potential, Shape Memory Alloy (SMA)

References

[1] P.Krulevitch, A.P. Lee, P.B. Ramsey, J.C. Trevino, J.Hamilton, M.A. Northrup, Thin film shape memory alloy microactuators, Journal of Microelectro-Mechanical Systems 5 (4) (1996), pp.270-282

DOI: 10.1109/84.546407

[2] S.Miyazaki, and A.Ishida, Martensitic transformation and shape memory behavior in sputter-deposited TiNi-base thin films, Materials Science and Engineering A Vol. 273-275 (1999), pp.106-133

DOI: 10.1016/s0921-5093(99)00292-0

[3] S.Miyazaki, K.Otsuka, C.M. Wayman, Morphological changes associated with the R-phase and martensitic transformations in Ti-Ni single crystals, ISIJ International, 29 (5) (1989), pp.423-429

DOI: 10.2355/isijinternational.29.423

[4] J.D. Busch, A.D. Johnson, C.H. Lee, Stevenson, D.A. et al., Shape-memory properties in Ni-Ti sputter-deposited film, Journal of Applied Physics, 68 (12) (1990), pp.6224-6228

DOI: 10.1063/1.346914

[5] K.R.C. Gisser, J.D. Busch, A.D. Johnson, A.B. Ellis, Oriented nickel-titanium shape memory alloy films prepared by annealing during deposition, Applied Physics Letters, 61(14) (1992), pp.1632-1634

DOI: 10.1063/1.108434

[6] CIMTEC2008 ike, Influence of substrate temperature on texture for deposited TiNi films, Proceedings of the 3rd International Conference on Smart Materials, Structures and Systems (CIMTEC 2008), State-of-the-art Research and Application of SMAs Technologies, 59 (2008), pp.30-34

[7] N.Ikenaga, Y.Kishi, Z.Yajima and N.Sakudo, Low Temperature Crystallization of TiNi Films by Ion Irradiation, The 8th European Symposium on Martensitic Transformations (ESOMAT 2009), 05010 (2009), published by EDP Sciences (www.esomat.org), DOI:10.1051/esomat/200905010, (2009)

DOI: 10.1051/esomat/200905010

[8] Y.Kishi, N.Ikenaga, N.Sakudo and Z.Yajima, Transforamation Behavior of Low Temperature Crystallized TiNi Shape Memory Alloy Films, The 8th European Symposium on Martensitic Transformations (ESOMAT 2009), 02012 (2009), published by EDP Sciences (www.esomat.org), DOI:10.1051/esomat/200902012, (2009)

DOI: 10.1051/esomat/200902012

[9] I.Odrobina, M.Kando, Discontinuous transitions between alpha and gamma regimes of rf capacitive discharge, Plasma Source Science and Technology, 5(3), (1996), pp.517-522

DOI: 10.1088/0963-0252/5/3/020
