Influence of Alumina Addition on Low Temperature Degradation of Y₂O₃-Coated Powder Based Y-TZP Ceramics

Abstract:

The influence of the addition of 0.25, 2 and 5 wt.% alumina on the mechanical properties and low temperature degradation (LTD) behaviour of 3 mol% yttria-coated ZrO₂ powder based Y-TZP ceramics was investigated, and compared to commercial powder based co-precipitated 3Y-TZPs with 0-0.25 wt.% Al₂O₃ addition. The ceramics were subjected to accelerated hydrothermal degradation in an autoclave in H₂O at 134°C up to 40 hrs. X-ray diffraction and Raman spectroscopy were used to assess the LTD behaviour. Incorporating the Y₂O₃ stabilizer by means of a coating method resulted in a higher LTD resistance without compromising the higher fracture toughness, compared to the co-precipitation method. Alumina addition did not significantly influence the mechanical properties of all Y-TZPs but significantly increased the LTD resistance of the Y-TZP ceramics. The LTD resistance of 0.25 wt% Al₂O₃ doped TZPs was substantially higher than that of ceramics containing 2 or 5 wt.% Al₂O₃, which had a comparable susceptibility. The highest LTD resistance for the 0.25 wt.% alumina doped ceramics could be correlated to the solubility limit of alumina in zirconia.

You might also be interested in these eBooks

13th International Ceramics Congress - Part A

View Preview

Info:

Periodical:

Advances in Science and Technology (Volume 87)

Pages:

139-144

DOI:

https://doi.org/10.4028/www.scientific.net/AST.87.139

Citation:

Cite this paper

Online since:

October 2014

Authors:

Fei Zhang*, Kim Vanmeensel, Masanao Inokoshi, Bart van Meerbeek, Ignace Naert, Jef Vleugels

Keywords:

Alumina, Coated 3Y-TZP, Degradation

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] C. Piconi, G. Maccauro, Biomaterials, 20 (1999) 1-25.

Google Scholar

[2] S. Lawson, J. Eur. Ceram. Soc., 15 (1995) 485-502.

Google Scholar

[3] M.E. Roy, L.A. Whiteside, B.J. Katerberg, J.A. Steiger, J. Biomed. Mater. Res., Part A, 83A (2007) 1096-1102.

DOI: 10.1002/jbm.a.31438

Google Scholar

[4] J. Vleugels, Z.X. Yuan, O.V.D. Biest, J. Eur. Ceram. Soc., (2002) 873–881.

Google Scholar

[5] G.R. Anstis, P. Chantikul, B.R. Lawn, D.B. Marshall, J. Am. Ceram. Soc., 64 (1981) 533-538.

Google Scholar

[6] H. Toraya, M. Yoshimura, S. Somiya, J. Am. Ceram. Soc., 67 (1984) C-119-C-121.

Google Scholar

[7] I.C. Clarke, M. Manaka, D.D. Green, P. Williams, G. Pezzotti, Y.H. Kim, M. Ries, N. Sugano, L. Sedel, C. Delauney, B.B. Nissan, T. Donaldson, G.A. Gustafson, J. Bone Joint Surg. Am., 4 (2003) 73-84.

DOI: 10.2106/00004623-200300004-00009

Google Scholar

[8] J. Chevalier, L. Gremillard, A.V. Virkar, D.R. Clarke, J. Am. Ceram. Soc., 92 (2009) 1901-(1920).

Google Scholar

[9] Y. Kawai, Dent. Mater. J., 30 (2011) 286.

Google Scholar

[10] F. Zhang, K. Vanmeensel, M. Inokoshi, M. Batuk, J. Hadermann, B. Van Meerbeek, I. Naert, J. Vleugels, J. Eur. Ceram. Soc., http: /dx. doi. org/10. 1016/j. jeurceramsoc. 2014. 02. 026 (2014).

DOI: 10.1016/j.jeurceramsoc.2014.02.026

Google Scholar

[11] M.A. Stough, J.R. Hellmann, J. Am. Ceram. Soc., 85 (2002) 2895-2902.

Google Scholar
