On-Body Chemo/Bio-Sensing - Opportunities and Challenges

Abstract:

In recent years, there has been significant progress in a number of sensing technologies related to on-body measurements, such as platforms for monitoring respiration, heart rate, location and movement. In these cases, the sensing element (s) are based on highly effective transducers that are increasingly integrated into garments such that they are becoming innocuous to the user. In contrast, the area of on-body chemical sensing remains highly under-developed. In this paper, we will address the significant challenges that are inhibiting the practical realisation of reliable chemical sensors and biosensors capable of generating accurate data in real time.

• Periodical: Advances in Science and Technology (Volume 96)
• Pages: 78-88
• DOI: https://doi.org/10.4028/www.scientific.net/AST.96.78
• Online since: October 2014
• Authors: Giusy Matzeu, Cormac Fay, Conor O’Quigley, Dylan Orpen, Simon Coleman, Andrew Kavanagh, Dermot Diamond*
• Keywords: Biological Fluids, Chemical Sensors, Non-Invasive Monitoring, Wearable
