Elastic-Plastic Fracture Mechanics Model for Planar Isotropic Porous Materials with Small Mixed-Mode Cracks

Abstract:

A porous panel with a small crack subjected to mixed-mode loads under yielding and plane stress conditions is examined here. The recently proposed modified Gurson’s yield criterion is adopted to account for the non-linear behavior of a porous panel with normal anisotropy but planar isotropy. Trends in the constant J contour, based upon a finite element analysis, are correlated with those of constant fatigue life contours under mixed-mode I and II loading conditions. The effects of both the anisotropy parameter and the porosity upon the J integral are then demonstrated. Simulation results show that the transverse strain dominates constant J contours on the -plane as the anisotropy parameter increases under the mixed-mode loads. However, constant J contours are less sensitive to the transverse strain even if a relatively larger void volume fraction appears in the panel.

• Periodical: Defect and Diffusion Forum (Volume 294)
• Pages: 39-47
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.294.39
• Online since: December 2009
• Authors: K.C. Liao
• Keywords: Anisotropy Parameter, J-Integral, Multiaxial Fatigue, Porous Material

References

[1] C.P. Yeh, W.X. Zhou and K. Wyatt: The International Society for Hybrid Microelectronics Vol. 19 (1996), p.120.

[2] J. Wang, Z. Qian, D. Zou and S. Liu: Trans. on ASME Journal of Electronic Packaging Vol. 120 (1998), p.179.

[3] K.H. Teo: IEEE/CMPT Electronics Packaging Technology Conference (1998), p.269.

[4] Q. Yao and J. Qu: Trans. on ASME Journal of Electronic Packaging Vol. 121 (1999), p.196.

[5] K. -C. Liao and H.H. Tsai: The 4th International Conference on Thermal & Mechanical Simulation and Experiments in Micro-electronics and Micro-systems, Aix-en-Provence, France, March 30 - April 2 (2003).

[6] A. Fatemi and D.F. Socie: Fatigue and Fracture of Engineering Materials and Structures Vol. 11 (1988), p.149.

[7] D.F. Socie: ASTM STP 1191 (1993; ), p.7.

[8] C. -C. Chu: J. Engineering Materials and Tech. Vol. 117 (1995), p.41.

[9] J.H. Underwood: ASTM STP 513 (1972), p.59.

[10] J.J. McGowan and M. Raymund: ASTM 677 (1979), p.365.

[11] I.S. Raju and Jr. J.C. Newman: J. Pressure Vessel Tech. Vol. 102 (1980), p.342.

[12] A.S. Kobayashi, A.F. Emery, N. Polvanich, W.J. Love: J. Pressure Vessel Tech. (1997), p.83.

[13] N.E. Dowling and J.A. Begley: ASTM STP 590 (1976), p.82.

[14] N.E. Dowling: ASTM STP 637 (1977), p.97.

[15] M. Zheng and H.W. Liu: J. Engineering Materials and Tech. Vol. 108 (1986), p.201.

[16] M.W. Brown and K.J. Miller: Institution of Mechanical Engineers Vol. 187 (1973), p.745.

[17] A. Nitta, T. Ogata and K. Kuwabara: Fatigue Fract. Engineering Materials Struct. Vol. 12 (1989), p.77.

[18] T. Ogata, A. Nitta and J.J. Blass: ASTM STP 1191 (1993), p.313.

[19] Y. Wang and J. Pan: Int. J. Fatigue Vol. 20 (1998), p.775.

[20] Y. Wang and J. Pan: Int. J. Solids and Structures Vol. 36 (1999), p.4543.

[21] Y. Wang and J. Pan: J. Pressure Vessel Tech. Vol. 123 (2001), p.2.

[22] Gurson AL. Continuum theory of ductile rupture by void growth: part I - yield criteria and flow rules for porous ductile media. J. Eng. Mater. Tech. 1977; 99: 2-15.

DOI: 10.2172/7351470

[23] V. Tvergaard: Int. J. Fract. Vol. 17 (1981), p.389.

[24] O. Richmond and RE. Smelser: Alcoa Technical Center Memorandum (1985).

[25] K. -C. Liao, J. Pan and S.C. Tang: Mech. Mater. Vol. 26 (1997), p.213.

[26] R. Hill: Roy. Soc. London Proc. Vol. 193A (1948), p.281.

[27] R. Hill: Math. Proc. Camb. Phil. Vol. 85 (1979), p.179.

[28] H.D. Hibbitt, B.I. Karlsson and E.P. Sorensen: ABAQUS user manual, Version 6. 7 (2007).

[29] J.W. Yoon, F. Barlat and R.E. Dick: SAE paper no. 2000-01-0774, Society of Automotive Engineers, Pennsylvania, Warrendale (2000), p.67.

[30] H. -M. Huang, J. Pan and S.C. Tang: Int. J. Plast. Vol. 16 (2000), p.611.
