Heat and Mass Transfer in an Inclined Bi-L-Shaped Layered Porous Media: Effect of Buoyancy Ration

Abstract:

The effect of buoyancy ratio on the two dimensional natural convection heat and mass transfer generated in an inclined square bi-L-shaped layered porous cavity filled with Newtonian fluid has been investigated numerically. Each porous layer is considered isotropic, homogeneous and saturated with the same fluid. The cavity is heated and salted from below where as the vertical walls are assumed to be adiabatic and impermeable. The physical model for the momentum conservation equation makes use of the Darcy-Brinkman-Forcheimer model, and the set of coupled equations is solved using a finite volume approach. The power-law scheme is used to evaluate the flow, heat and mass fluxes across each of the control volume boundaries. Tri diagonal matrix algorithm with under-relaxation is used in conjunction with iterations to solve the nonlinear discretized equations. An in-house code developed for this study is validated using previous studies. The results are presented graphically in terms of streamlines, isotherms and iso-concentrations. In addition, the heat and mass transfer rate in the cavity is measured in terms of the average Nusselt and Sherwood numbers.

• Periodical: Defect and Diffusion Forum (Volume 406)
• Pages: 87-97
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.406.87
• Online since: January 2021
• Authors: Latreche Abdelkrim*, Djezzar Mahfoud
• Keywords: Buoyancy Ratio, Darcy-Brinkman-Forcheimer Model, Heat and Mass Transfer, Natural Convection, Porous Media
