Numerical Study of Combined Surface Radiation and Natural Convection in Vertical Conical Annular Enclosure

Abstract:

The present study investigates the combined free convection and surface radiation in a conical annular cylinder filled with air (Pr=0.71). The steady-state continuity, Navier–Stokes and energy equations were carried out by the finite volume method, and the Discrete Ordinates Method (DOM) was used to solve the radiative heat transfer equation (RTE). The boundary conditions are such that the inner and the outer radius of cone are maintained at hot (T_h) and cold (T_c) isothermal temperature. The horizontal upper and lower walls are assumed to be isolated. Concerning the radiation exchange, we consider that the fluid (air) is transparent, so only the solid surfaces contribute to the radiation exchange and assumed to be diffuse-gray. The computations are performed for Rayleigh number (Ra) in the range 10³≤Ra≤10⁶ , the surface emissivity (ε) 0≤ε≤1 and the cone angle () 63o, 76o, 80o and 84o. The key parameters for this analysis are considered as Rayleigh number (Ra), surface emissivity (ε) and the cone angle (). Results are presented in terms of isotherms, streamlines and the average Nusselt numbers.

• Periodical: Defect and Diffusion Forum (Volume 408)
• Pages: 19-32
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.408.19
• Online since: April 2021
• Authors: Mohamed Amine Medebber*, Belkacem Ould Said, Noureddine Retiel
• Keywords: Average Nusselt Number, Coaxial Conical Cavity, Finite Volume Method, Natural Convection, Surface Radiation

References

[1] M. Behnia, J. A. Reizes and G. De Vahl Davis, Combined radiation and natural convection in a rectangular cavity with a transparent wall and containing a nonparticipating fluid. Int. J. Numer. Methods Fluids, vol. 10, pp.305-325, (1990).

DOI: 10.1002/fld.1650100306

[2] C. Balaji and S. P. Venkateshan, Interaction of surface radiation with free convection in a square cavity, Int. J. Heat and Fluid Flow, vol. 14, n° 3, pp.260-267, (1993).

DOI: 10.1016/0142-727x(93)90057-t

[3] M. Akiyama and Q. P. Chong, Numerical analysis of natural convection with surface radiation in a square enclosure, Numerical Heat Transfer, Part A, vol. 31, pp.419-433, (1997).

DOI: 10.1080/10407789708913899

[4] Ramesh, and S. P. Venkateshan, Effect of surface radiation on natural convection in a square enclosure, J. Thermophys. Heat Transfer, vol. 13, n°. 3, pp.299-301, (1999).

DOI: 10.2514/2.6458

[5] N. Ramesh and W. Merzkirch, Combined convection and radiative heat transfer in side-vented open cavities, Int. J. Heat and Fluid Flow, vol. 22, pp.180-187, (2001).

DOI: 10.1016/s0142-727x(00)00080-1

[6] E. H. Ridouane, M. Hasnaoui, A. Amahmid and A. Raji, Interaction between natural convection and radiation in a square cavity heated from below, Numerical Heat Transfer, Part A, vol. 45, pp.289-311, (2004).

DOI: 10.1080/10407780490250373

[7] E. H. Ridouane, M. Hasnaoui and A. Campo, Effects of surface radiation on natural convection in a Rayleigh-Bénard square enclosure: steady and unsteady conditions, Heat Mass Transfer, vol. 42, pp.214-225, (2006).

DOI: 10.1007/s00231-005-0012-7

[8] H. Wang, S. Xin et P. Le Quéré, Etude numérique du couplage de la convection naturelle avec le rayonnement de surfaces en cavité carrée remplie d'air, Comptes Rendus Mécanique, vol. 344, pp.48-57, (2006).

DOI: 10.1016/j.crme.2005.10.011

[9] H. Nouanegue, A. Muftuoglu and E. Bilgen, Conjugate heat transfer by natural convection, conduction and radiation in open cavities, Int. J. Heat Mass Transfer, vol. 51, pp.6054-6062, (2008).

DOI: 10.1016/j.ijheatmasstransfer.2008.05.009

[10] C. Balaji, S.P. Venkateshan, Interaction of surface radiation with free convection in a square cavity, Int. J. Heat Fluid Flow 14 (3) (1993) 260–267.

DOI: 10.1016/0142-727x(93)90057-t

[11] K. Velusamy, T. Sundararajan and K. Seetharamu, Interaction effects between surface radiation and turbulent natural convection in square and rectangular enclosures. Journal of Heat Transfer, vol. 123, pp.1062-1070, (2001).

DOI: 10.1115/1.1409259

[12] A. Mezrhab, H. Bouali, H. Amaoui, M. Bouzidi, Computation of combined natural-convection and radiation heat-transfer in a cavity having a square body at its center, Appl. Energy 83 (2006) 1004–1023.

DOI: 10.1016/j.apenergy.2005.09.006

[13] M. Sankar, S. Kiran, G.K. Ramesh, O.D. Makinde. Natural convection in a non-uniformly heated vertical annular cavity, Defect and Diffusion Forum. 377 (2017) 189-199.

DOI: 10.4028/www.scientific.net/ddf.377.189

[14] S. Amraqui, A. Mezrhab, C. Abid. Combined Natural Convection and Surface Radiation in Solar Collector Equipped with Partitions, Applied Solar Energy. 47 (1) (2011) 36-47.

DOI: 10.3103/s0003701x11010051

[15] N. Ramesh, and S. P. Venkateshan, Effect of surface radiation on natural convection in a square enclosure. J. Thermophys. Heat Transfer, vol. 1, n° 3, pp.299-301, (1999).

DOI: 10.2514/2.6458

[16] C. K. Krishnaprakas, and K. B. Narayane, Interaction of radiation with natural convection. J. Thermophys. Heat Transfer, vol. 13, n° 3, pp.387-390, (1999).

[17] M. Behnia, J.A. Reizes, G. de Vahl Davis, Natural convection in a cavity with a window, in: Proceedings of the AIAA 20th Thermophysics Conference, Williamsburg, VA, June 19–21, (1985).

[18] A. Amrani, N. Dihmani, S. Amraqui, A. Mezrhab. Numerical evaluation of natural convection heat transfer in a supply-air paziaud window, Computational Thermal Sciences. 6 (5) (2014) 383–395.

DOI: 10.1615/computthermalscien.2014011147

[19] Z. Tan, J.R. Howell, Combined radiation and natural convection in a two dimensional participating square medium, Int. J. Heat Mass Transfer 34 (3) (1991) 785–793.

DOI: 10.1016/0017-9310(91)90125-x

[20] C.Y. Han, S.W. Baek, The effects of radiation on natural convection in a rectangular enclosure divided by two partitions, Numer. Heat Transfer Part A 37 (2000) 249–270.

DOI: 10.1080/104077800274280

[21] B. Mondal, S.C. Mishra, Simulation of natural convection in the presence of volumetric radiation using the lattice Boltzmann method, Numer. Heat Transfer Part A 55 (2009) 18–41.

DOI: 10.1080/10407780802603121

[22] Vajravelu, K., and Nayfeh, L., Hydromagnetic Convection at a Cone and a Wedge,, International Communication Heat Mass Transfer, Vol. 19, No. 5, 1992, p.701–710.

DOI: 10.1016/0735-1933(92)90052-j

[23] Chamkha, A. J., Coupled Heat and Mass Transfer by Natural Convection about a Truncated Cone in the Presence of Magnetic Field and Radiation Effects,, Numerical Heat Transfer, Part A,Vol. 39, No. 5, 2001, p.511–530.

DOI: 10.1080/10407780120202

[24] Takhar, H. S., Chamkha, A. J., and Nath, G., Unsteady Mixed Convection Flow from a RotatingVertical Cone with a Magnetic Field,, Heat Mass Transfer, Vol. 39, No. 4, 2003, p.297–304.

DOI: 10.1007/s00231-002-0400-1

[25] Chamkha, A. J., and Al-Mudhaf, A., Unsteady Heat and Mass Transfer froma RotatingVerticalConewith aMagnetic Field and HeatGeneration or Absorption Effects,, International Journal Thermal Sciences, Vol. 44, No. 3, 2005, p.267–276.

DOI: 10.1016/j.ijthermalsci.2004.06.005

[26] Mohiddin, S. G., Anwar Bég, O., andVarma, K. S.V., Numerical Study of Free Convective MHD Flow Past a Vertical Cone in Non-Darcian Porous Media,, Theoretical and Applied Mechanics, Vol. 41, No. 2, 2014, p.119–140.

DOI: 10.2298/tam1402119g

[27] M. F. Modest. :Radiative heat transfert. McGraw-Hill, New York, (1993).

[28] Patankar, S. Numerical Heat Transfer and Fluid Flow, Hemisphere, New York, (1980).

[29] Dua, S. S. and Cheng, P. Multi-Dimensional Radiative Transfer in Non-isothermal Cylindrical Media with Non-isothermal Bounding Walls, Int. J. Heat Mass Transfer, Vol. 18, (1975) 245-259.

DOI: 10.1016/0017-9310(75)90157-x
