Dynamic Analysis of CNC Machine Tool Structures Using FBGMT and R-Flex Flexible Multibody Dynamics Approaches

Abstract:

This study presents an integrated rigid flexible dynamic analysis of a CNC machine tool column using the Full Body General Motion Transfer (FBGMT) method and R-Flex flexible body modeling in RecurDyn, validated through comparison with ANSYS finite element modal results. The FBGMT approach simulated the vertical translation of the spindle head driven by a ball screw linear guide system, generating realistic motion data for structural evaluation. The R-Flex model converted the column into a flexible body using an RFI-based contact method, enabling the assessment of deformation, stress, and strain at three distinct tool head positions top, mid, and bottom. Modal analysis was performed in both RecurDyn and ANSYS under matched geometry, mesh density, and boundary conditions to verify frequency and mode shape consistency. Results show that displacement and stress increase as the tool head moves downward, with all responses remaining within elastic limits. Frequency deviation between RecurDyn and ANSYS remained within engineering tolerance, and mode shapes demonstrated strong correlation. This integrated workflow demonstrates a robust methodology for predicting CNC structural performance under realistic motion induced loading.

• Periodical: Defect and Diffusion Forum (Volume 453)
• Pages: 33-44
• DOI: https://doi.org/10.4028/p-Zzp2K0
• Online since: July 2026
• Authors: Yunn Lin Hwang*, Nabeel Ahmad
• Keywords: CNC Machine Tool, FBGMT, Modal Analysis, Multibody Dynamics, R-Flex

References

[1] M. Bratland, B. Haugen, and T. Rølvåg, "Modal analysis of active flexible multibody systems," Computers & Structures,Vol. 89, No. 9-10, pp.750-761, 2011.

DOI: 10.1016/j.compstruc.2011.02.010

[2] J. Fehr and P. Eberhard, "Simulation process of flexible multibody systems with non-modal model order reduction techniques," Multibody System Dynamics,Vol. 25, No. 3, pp.313-334, 2011.

DOI: 10.1007/s11044-010-9238-3

[3] R. R. Craig Jr and M. C. Bampton, "Coupling of substructures for dynamic analyses," AIAA journal,Vol. 6, No. 7, pp.1313-1319, 1968.

DOI: 10.2514/3.4741

[4] X. Gang, Z. Yan, Z. Fanli, and C. Liping, "Modelling and Simulation of the Coupled Rigidflexible Multibody Systems in MWorks," in Proc. 9th International Modelica Conference, Munich, Germany, 2012, pp.405-416

DOI: 10.3384/ecp12076405

[5] C. E. Okwudire and Y. Altintas, "Hybrid modeling of ball screw drives with coupled axial, torsional, and lateral dynamics," 2009.

DOI: 10.1115/1.3125887

[6] L. Jin, C. Li, X. Wang, and L. Xie, "A dynamic stiffness model for high-speed ball screw pair with the mass center of screw nut considered," Mechanics & Industry,Vol. 24, p.21, 2023.

DOI: 10.1051/meca/2023018

[7] M. Wang, B. Wen, Q. Han, Y. Sun, and C. Yu, "Dynamic characteristics of a misaligned rigid rotor system with flexible supports," Shock and Vibration,Vol. 2021, No. 1, p.8876190, 2021.

DOI: 10.1155/2021/8876190

[8] Z. Wei, Z. Wang, D. Li, and D. Liang, "Rigid-flexible coupling dynamic modelling and dynamic accuracy analysis of planar cam four-bar mechanism with multiple clearance joints," Proceedings of the Institution of Mechanical Engineers, Part K: Journal of Multi-body Dynamics,Vol. 238, No. 3, pp.421-444, 2024.

DOI: 10.1177/14644193241264076

[9] M. Zaeh and D. Siedl, "A new method for simulation of machining performance by integrating finite element and multi-body simulation for machine tools," CIRP annals,Vol. 56, No. 1, pp.383-386, 2007.

DOI: 10.1016/j.cirp.2007.05.089
