Exploring the Application of Computer-Aided Design in Structural Designs for Sustainable Infrastructure Projects

Abstract:

This study explores the role of Computer-Aided Design (CAD) in advancing sustainable structural design, focusing on a portal frame warehouse as a case study. As construction demands shift towards sustainability, CAD tools such as AutoCAD, ProtaStructure, and Tekla Structures offer enhanced precision, design optimization, and material efficiency. The research compares manual method and CAD-based approaches in designing a 20 m × 50 m steel portal frame warehouse, following BS 5950 standards. The portar frame design involved manually analysing loads, selecting sections, and designing columns, base plates, and footings, while CAD softwares performed 3D modelling and automatic code checks. After the analysis and design, 203×203×46 UC (276 kg) was obtained at a rate of ₦331,200/section for manual approach, while with CAD approach, 254×254×73 UB (438 kg) at a rate of ₦525,600/section was obtained. However, for the footing. 0.216 m³ at ₦9,720 was obtained for manual approach, while 0.8 m³ at ₦23,040 was obtained for CAD approach. In total, for a section, manual design will cost ₦653,398 while CAD design cost will ₦864,814. It is recommended that CAD-based design should be prioritized for large-scale or safety-critical infrastructure due to its precision, efficiency, and compliance with modern codes. For smaller or budget-limited projects, a hybrid approach combining manual and CAD methods is suggested. Investment in CAD training and software can drive long-term sustainability and structural resilience.

• Periodical: Engineering Headway (Volume 33)
• Pages: 299-306
• DOI: https://doi.org/10.4028/p-9MkThI
• Online since: February 2026
• Authors: S. L. Akingbonmire*, O. O. Fasida
• Keywords: Computer-Aided Design, Portal Frame Warehouse, Structural Design, Sustainable Infrastructure

References

[1] C. Eastman, P. Teicholz, R. Sacks, and K. Liston, BIM Handbook: A Guide to Building Information Modeling for Owners, Managers, Designers, Engineers and Contractors. 2nd ed. Hoboken: Wiley (2011)

DOI: 10.1002/9780470261309

[2] D. Jones and T. Lane, The Practical Guide to AutoCAD in Construction Design. London: Pearson Education (2013)

[3] M. Kelleher, Sustainable Design and Construction Using BIM Tools. J. Green Building, (2019) 14(1), 105–117.

[4] S. Azhar, M. Khalfan and T. Maqsood, Building information modeling (BIM): now and beyond. Constr. Econ. and Bdg., 12(4), (2018) 15–28.

DOI: 10.5130/ajceb.v12i4.3032

[5] B. Hwang and W. J. Ng, Project Management for Green Construction: Challenges, Solutions and Opportunities. Int. J. of Proj. Mgt., 31(2), (2019) 272–284.

[6] J. Rockström, W. Steffen, K. Noone, Å. Persson, F. S. Chapin III, E. F. Lambin, T. M. Lenton, M. Scheffer, C. Folke, H. J. Schellnhuber and B. Nykvist, A Safe Operating Space for Humanity. Nature, 461(7263), (2017) 472–475.

DOI: 10.1038/461472a

[7] L. Ding, Y. Zhou and B. Akinci, Building Information Modeling for Construction Safety Management: A Review. Aut. in Constr., 96 (2017) 434–449.

[8] R. Oxman, Theory and Design in the First Digital Age. Design Studies, 52 (2017) 4–39.

[9] M. Mansour, J. Fiksel and A. Basu, The Path to Sustainability: Resilience in Industrial Ecosystems. Sustainable Production and Consumption, 11 (2021)11–25.

[10] G. P. Luth, B. R. Schwegler and R. T. Shilcrat, Putting Construction Engineering and Management Back on the Map. J. of Constr. Eng. and Mgt., 140 (5), (2014) 1–7.

[11] R. Sacks, U. Gurevich, V. Kalganova and T. Oron-Gilad, Modeling and Measuring Design Information Quality in BIM-based Design. Automation in Construction, (2018) 92, 292–306.

[12] CESDb, AutoCAD - Description and Capabilities. [online] Civil Engineering Software Database. Available at: https://www.cesdb.com/autocad.html [Accessed 12 June 2025] (2016).

[13] Civil Engineers World, Comparison Between Manual and Computer-Aided Design (CAD) in Structural Engineering. [online] Available at: www.civilengineersworld.com [Accessed 12 June 2025], (2020).

[14] CESDb, Tekla Structures - Overview and Features. [online] Civil Engineering Software Database. Available at: https://www.cesdb.com/tekla-structures.html [Accessed 12 June 2025] (2020).

[15] Prota Software, ProtaStructure Suite Overview. [online] Available at: https://www.protasoftware.com [Accessed 12 June 2025] (2020).

[16] Prota Software, ProtaStructure 2024 Features. [online] Available at: https://www.protasoftware.com [Accessed 12 June 2025] (2024).

[17] Trimble Solutions, Tekla Structures for Structural Engineering. [online] Available at: https://www.tekla.com [Accessed 12 June 2025] (2020).
