Investigation on Micro Electric Discharge Machining of Wire Arc Additive Manufactured Inconel 625

Abstract:

This study investigates the optimization of machining parameters for fabricating micro-holes in Wire Arc Additive Manufactured (WAAM) Inconel 625 using Micro Electric Discharge Machining (Micro EDM). An experimental design based on the Taguchi L9 orthogonal array was employed, focusing on the effects of input current (Ip), pulse-on time (Ton), and pulse-off time (Toff). Using copper electrodes, 800 µm diameter micro-holes were machined, and responses such as Material Removal Rate (MRR), Tool Wear Rate (TWR), and dimensional accuracy (DA) were analyzed. Signal-to-Noise (S/N) ratio analysis was used to determine optimal machining conditions, achieving maximum MRR, minimum TWR, and enhanced DA. The results revealed that the optimal parameters for achieving these objectives were Ip = 2 A, Ton = 5 µs, and Toff = 9 µs. This research highlights the effectiveness of the Taguchi method and S/N analysis in enhancing machining performance for WAAM Inconel 625, contributing to improved precision and efficiency in manufacturing processes.

• Periodical: Engineering Headway (Volume 41)
• Pages: 13-24
• DOI: https://doi.org/10.4028/p-At8sQh
• Online since: July 2026
• Authors: A. Ragul*, J. Pradeep Kumar, Somasundara Vinoth
• Keywords: Inconel 625, Micro EDM, Micro-Holes, Optimisation

References

[1] Yao Sun et al. (2022) A comprehensive review on fabrication of ultra small micro tools via electrical discharge machining-based methods. The International Journal of Advanced Manufacturing Technology 118:703–735.

DOI: 10.1007/s00170-021-07976-6

[2] R. Naveen Anthuvan, V. Krishnaraj (2020) Effect of coated and treated electrodes on Micro-EDM characteristics of Ti-6Al-4V. Journal of the Brazilian Society of Mechanical Sciences and Engineering 42-517.

DOI: 10.1007/s40430-020-02578-x

[3] Amit Kumar Singh, Promod Kumar, M. Chandrasekaran (2020) Experimental study on drilling micro-hole through micro-EDM and optimization of multiple performance characteristics. Journal of the Brazilian Society of Mechanical Sciences and Engineering 42:506.

DOI: 10.1007/s40430-020-02595-w

[4] Ferhat Ceritbinmez, Ali Gunen, Ugur Gurol, Gurel Cam (2023) A comparative study on drillability of Inconel 625 alloy fabricated by wire arc additive manufacturing. Journal of Manufacturing Processes 89:150-169.

DOI: 10.1016/j.jmapro.2023.01.072

[5] Amiya Kumar Sahoo, Dhananjay R.Mishra (2024) Experimental characteristic evaluation of micro hole EDM drilling of Ni51.58 Ti48.34 Open Access alloy with copper electrode and response optimization using GRG assisted with GA. Journal of Engineering and Applied Science 71:117.

DOI: 10.1186/s44147-024-00447-1

[6] B. Murali et al. (2023) Improvement of micro-EDM drilling efficiency on Inconel 625. Journal on Materials Today: Proceedings 2214-7853.

DOI: 10.1016/j.matpr.2023.08.315

[7] Chinnasami Sivaji et al (2023) An Optimization of Micro-EDM Drilling Process parameters of Inconel 625. Journal on Materials and its Characterization 2583-6412.

DOI: 10.46632/jmc/2/4/5

[8] Ashok Kumar Sharma et al. (2024) Experimental analysis of Inconel 625 alloy to enhance the dimensional accuracy with vibration assisted micro-EDM. International Journal on Interactive Design and Manufacturing (IJIDeM) 7495–7509.

DOI: 10.1007/s12008-023-01228-5

[9] S.Rajamanickam, J. Prasanna, C.Chandrasekhara Sastry (2020) Analysis of high aspect ratio small holes in rapid electrical discharge machining of superalloys using Taguchi and TOPSIS. Journal of the Brazilian Society of Mechanical Sciences and Engineering 42:99.

DOI: 10.1007/s40430-020-2180-2

[10] Rajesh Sahoo, Siddhartha Kar, Promod Kumar Patowar (2022) Experimental study on Titanium diamond by fabricating micro-holes using Micro-EDM with Taguchi's method and response surface method. Engineering Research Express 115-133.

DOI: 10.1088/2631-8695/abcc46
