Renewable Night Cooled Chill Water Source for Energy Efficient Indoor Radiant Cooling

Abstract:

This study investigates cooling of water at night in Malaysian climate as renewable cooling medium source for radiant cooling purpose. An experiment with a 1.95 m² steel roof rig structure was constructed and night cooling cycle was conducted during the hot season and cold season of the year. Regression model was developed to predict water temperature after the night cooling process and the corresponding water and roof ratio was established. An annual simulation of a low income home model retrofitted with radiant cooling system charged by night cooled water as cooling medium shows that 99% of the time the thermal condition could meet ISO 7730 category C PMV between-0.7 and + 0.7 . For an outdoor ASHRAE design day condition, the peak indoor operative temperature of 37oC could be lowered to about 30oC with the use of radiant cooling system. The calculated energy saving for the home model was 85% or about 15% of the conventional air system operating cost.

• Periodical: International Journal of Engineering Research in Africa (Volume 26)
• Pages: 86-98
• DOI: https://doi.org/10.4028/www.scientific.net/JERA.26.86
• Online since: October 2016
• Authors: Muhammad Syukri Imran*, Azhaili Baharun, Siti Halipah Ibrahim, Wan Azlan bin Wan Zainal Abidin
• Keywords: Energy Efficiency, Long Wave Radiation, Nocturnal Cooling, Operative Temperature, Predicted Mean Vote, Radiant Cooling, Regression Model, Sky Temperature, Thermal Comfort

References

[1] L. S. Nielsen, Building Integrated System Design for Sustainable Heating and Cooling, REHVA J., no. February, p.24–27, (2012).

[2] P. Vangtook and S. Chirarattananon, Application of radiant cooling as a passive cooling option in hot humid climate, Build. Environ., vol. 42, no. 2, p.543–556, Feb. (2007).

DOI: 10.1016/j.buildenv.2005.09.014

[3] R. D. Watson and K. S. Chapman, Radiant Heating and Cooling handbook. McGraw-Hill, (2002).

[4] Uponor Inc, UPONOR Radiant Cooling Design Manual, 1st ed. Apple Vallley MN: Uponor, Inc., (2013).

[5] A. S. Binghooth and Z. a. Zainal, Performance of desiccant dehumidification with hydronic radiant cooling system in hot humid climates, Energy Build., vol. 51, p.1–5, Aug. (2012).

DOI: 10.1016/j.enbuild.2012.01.031

[6] A. Hamza, I. M. S. Taha, and I. M. Ismail, Cooling of water flowing thorugh a night sky radiator, Sol. Energy, vol. 55, no. 4, (1995).

DOI: 10.1016/0038-092x(95)00030-u

[7] A. H. H. Ali, Passive cooling of water at night in uninsulated open tank in hot arid areas, Energy Convers. Manag., vol. 48, no. 1, p.93–100, Jan. (2007).

DOI: 10.1016/j.enconman.2006.05.012

[8] P. D. Dan and J. C. V. Chinnappa, The Cooling Of Water Flowing Over An Inclined Surface Exposed To The Night Sky, Sol. Wind Technol., vol. 6, no. 1, p.41–50, (1989).

DOI: 10.1016/0741-983x(89)90036-2

[9] N. Chotivisarut, A. Nuntaphan, and T. Kiatsiriroat, Seasonal cooling load reduction of building by thermosyphon heat pipe radiator in different climate areas, Renew. Energy, vol. 38, no. 1, p.188–194, Feb. (2012).

DOI: 10.1016/j.renene.2011.07.021

[10] T. Runsheng, Y. Etzion, and E. Erell, Experimental studies on a novel roof pond configuration for the cooling of buildings, Renew. Energy, vol. 28, no. 10, p.1513–1522, Aug. (2003).

DOI: 10.1016/s0960-1481(03)00002-8

[11] E. Erell and Y. Etzion, Radiative cooling of buildings with flat-plate solar collectors, Build. Environ., vol. 35, no. 4, p.297–305, May (2000).

DOI: 10.1016/s0360-1323(99)00019-0

[12] J. Sima, O. Sikula, K. Kosutova, and J. Plasek, Theoretical Evaluation of Night Sky Cooling in the Czech Republic, Energy Procedia, vol. 48, p.645–653, (2014).

DOI: 10.1016/j.egypro.2014.02.075

[13] G. Heidarinejad, M. Farmahini, and S. Delfani, Investigation of a hybrid system of nocturnal radiative cooling and direct evaporative cooling, Build. Environ., vol. 45, no. 6, p.1521–1528, (2010).

DOI: 10.1016/j.buildenv.2010.01.003

[14] S. Zhang and J. Niu, Cooling performance of nocturnal radiative cooling combined with microencapsulated phase change material (MPCM) slurry storage, Energy Build., vol. 54, p.122–130, Nov. (2012).

DOI: 10.1016/j.enbuild.2012.07.041

[15] R. T. Dobson, Thermal modelling of a night sky radiation cooling system, J. Energy South Africa, vol. 16, no. 2, p.20–31, (2005).

DOI: 10.17159/2413-3051/2005/v16i2a3184

[16] J. a. Duffie and W. a. Beckman, Solar Engineering of Thermal Processes, 4th ed. New Jersey: Wiley, (2013).

[17] C. Cândido, R. J. De Dear, R. Lamberts, and L. Bittencourt, Air movement acceptability limits and thermal comfort in Brazil's hot humid climate zone, Build. Environ., vol. 45, p.222–229, (2010).

DOI: 10.1016/j.buildenv.2009.06.005

[18] S. H. Ibrahim and J. A. Tinker, Improvements to thermal comfort in low-income housing in Malaysia, in Conference on Sustainable Building South East Asia, (2005).

[19] S. Rajeh, Wind Ventilation of Terrace Housing in Malaysia, in ISI-UTM International Convention and Exposition, (1994).

[20] H. M. Kamar, N. Kamsah, M. M. Tap, and K. A. M. Salimin, Assessment of thermal comfort in a naturally ventilated residential terrace house, in The 4th International Meeting of Advances in Thermofluids (IMAT 2011), 2012, vol. 1440, no. 2012, p.247.

DOI: 10.1063/1.4704224

[21] M. G. Normah, K. Y. Lau, and S. Mohd. Yusoff, Thermal analysis of Malaysian double storey housing - low/medium cost unit, in The 4th International Meeting of Advances in Thermofluids (IMAT 2011), 2012, vol. 1440, no. 1440, p.513–520.

DOI: 10.1063/1.4704257

[22] ANSI/ASHRAE, Standard 55-2013 Thermal Environmental Conditions for Human Occupancy, vol. 8400. (2013).

[23] ISO, EN ISO 7730 Ergonomics of the thermal environment — Analytical determination and interpretation of thermal comfort using calculation of the PMV and PPD indices and local thermal comfort criteria, 3rd ed. Switzerland: ISO, (2005).

DOI: 10.3403/30046382

[24] ASHRAE, Chapter 14 . Climatic Design Information, in ASHRAE Handbook Fundemental, 2014th ed., Atlanta: ASHRAE, 2014, p.1–43.
