Development of a Triple Band Notched UWB Antenna

Abstract:

In this paper, a microstrip line-fed rectangular-shaped ultra-wideband (UWB) antenna offering triple-band notch characteristics is proposed. The notching was done primarily to provide rejection for Wi-Max (3.3-3.7 GHz), WLAN2 (5.15-5.825 GHz), and ITU (8.025-8.4 GHz) through the combination of slots and a modified electromagnetic band gap (M-EBG). The antenna was simulated using HFSS and CST modelling tools. The antenna was able to notch three frequencies from narrow band communication systems (Wi-Max, WLAN2, and ITU), causing interference within the UWB band. The gain of the system over the operating frequency, the current distributions, and the impedance covered were studied to assess the effectiveness of the antenna. The proposed antenna is simple and compact, with a total antenna size of 19 mm by 24 mm and a wide bandwidth (3.2 to 12.5 GHz). Satisfactory results have been obtained when its performance was analyzed. A stable radiation characteristic is observed with a radiation efficiency of 94% when operating at a UWB resonant frequency of 6.85 GHz with a total gain between -10 dB and 5 dB within the range of the frequency band of 3.2 to 12.3 GHz.

• Periodical: International Journal of Engineering Research in Africa (Volume 63)
• Pages: 97-118
• DOI: https://doi.org/10.4028/p-525842
• Online since: March 2023
• Authors: Gabriel Fadehan, Yekeen O. Olasoji, Kazeem Bolade Adedeji*
• Keywords: Antenna, EBG, Microstrip, Omnidirectional, Radiation Pattern, Ultra-Wide Band, Via
