A Two-Color Heterodyne Interferometer Based on Diffraction Grating for Displacement Measurement

Abstract:

A two-color heterodyne interferometer based on the movement of the optical diffraction grating is proposed. The method allows us to measure the phase of synthetic wavelength f s directly and with high accuracy to extend the range of unambiguity for interferometric measurements by using two close wavelengths. Our experiment results show that the uncertainty in displacement measurement caused by the uncertainty in f s is 0.20 µm, smaller than the half of a single wavelength we used. The fringe order of a single wavelength can be determined without ambiguity. The uncertainty in displacement measurement can be improved further by using a single wavelength.

• Periodical: Key Engineering Materials (Volumes 295-296)
• Pages: 189-194
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.295-296.189
• Online since: October 2005
• Authors: G.H. Wu, Z.J. Cai, Li Jiang Zeng
• Keywords: Displacement, Grating, Heterodyne Interferometer, Synthetic Wavelength

References

[1] P.J. de Groot: Applied Optics, Vol. 33 (1994), p.5948.

[2] R. dandliker, R. Thalmann and D. Prongue: Optics Letters, Vol. 13 (1988), p.339.

[3] E. Gelmini, U. Minoni and F. Docchio: Optics Letters, Vol. 19 (1994), p.213.

[4] S. Yokoyama, J. Ohnishi, S. Iwasaki, K. Seta, H. Matsumoto and N. Suzuki: Measurement Science and Technology, Vol. 10 (1999), p.1233.

[5] L. Zeng, K. Seta, H. Matsumoto and S. Iwashaki: Measurement Science and Technology, Vol. 10 (1999), p.587.

[6] V. Mahal and A. Arie: Applied Optics, Vol. 35 (1996), p.3010.

[7] Y. Zhao, T. Zhou and D. Li: Optical Engineering, Vol. 38 (1999), p.246.
