Finite Element Modeling of Damage Formation in Rubber-Toughened Polymer

Abstract:

Microscopic studies on the toughening mechanism of rubber-toughened PMMA (RTPMMA) were carried out using a polarizing optical microscope (POM) and a transmission electron microscope (TEM). POM result showed that in a typical RT-PMMA, a damage zone was developed in the vicinity of crack-tip, and therefore, it was considered that energy dissipation due to the damage zone development was the primary toughening mechanism. TEM result exhibited that the damage zone was a crowd of micro-crazes generated around rubber particles in the vicinity of notch-tip. Finite element analysis was then performed to simulate such damage formations in crack-tip region. Macro-scale and micro-scale models were developed to simulate damage zone formation and micro-crazing, respectively, with use of a damage model. It was shown that the damage model introduced was successfully applied to predict such kind of macro-damage and micro-craze formations.

• Periodical: Key Engineering Materials (Volumes 297-300)
• Pages: 1019-1024
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.297-300.1019
• Online since: November 2005
• Authors: Mitsugu Todo, Yoshihiro Fukuya, Seiya Hagihara, Kazuo Arakawa
• Keywords: Crazing, Damage Zone, Finite Element Analysis (FEA), Polymer Blend, Rubber Modification

References

[1] M. Todo, K. Takahashi, Ph. Beguelin and H.H. Kausch: JSME Inter. J. A-42, 1 (1999), p.49.

[2] M. Todo, K. Takahashi, P. -Y.B. Jar and Ph. Beguelin: JSME Inter. J. A-42, 4 (1999), p.585.

[3] M. Todo, K. Takahashi, P. -Y.B. Jar and Ph. Beguelin: Proc. 11th Inter. Conf. Deform. Yeild Frac. Poly. Cambridge, UK (2000), p.225.

[4] M. Tohdoh, S.K. Chaturvedi and R.L. Sierakowski: Inter. J. Frac. 75 (1996), p.285.

[5] M. Todo, S.K. Chaturvedi and R.L. Sierakowski: Inter. J. Frac. 85 (1997), p.301.
