Thermal Stress Analysis for Air Inlet Part of Ramjet

Abstract:

The purpose of this study is to estimate structural characteristic for air inlet part of ramjet in condition of flight at 12-15km height. Because air inlet part of ramjet is heated up to 700oK, high temperature properties such as Young’s modulus, thermal expansion coefficients and thermal conductivity coefficients are applied to the analysis. The analysis of transient temperature and thermal stress was performed by the finite element method with nonlinear code ABAQUS. The analysis was performed using several thermal coefficient and material properties to select preliminary design model for flight condition. Thermal boundary conditions were applied at ramjet inlet part until 0.01sec. The results of the analysis recommend tendency of thermal stress and temperature distribution. These are useful to select the structural material and to determine shape of air inlet part which satisfy the structural design safety.

• Periodical: Key Engineering Materials (Volumes 297-300)
• Pages: 2253-2260
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.297-300.2253
• Online since: November 2005
• Authors: Song Heo Koo, Young Shin Lee, Jae Hoon Kim, S.J. Kim, Young Jin Choi
• Keywords: Ramjet Dome Port, Thermal Analysis, Transient

References

[1] S. Sato, K. Tsuyuki and S.C. Hwang: Analysis of Thermal Stresses and Evaluation of the Thermal Shock Resistances of Graphite Crucibles, Conference of APCFS and ATEM '01, JSME-MMD (2001), pp.499-504.

DOI: 10.1299/jsmeatemapcfs.1.01.203.0_499

[2] S. Amada, W.Y. Nong, Q.Z. Min and S. Akiuama: Thermal Shock Resistance of Carbon-Carbon (C/C) Composite by Laser Irradiation Technique, Journal of Ceramics International Vol. 25 (1999), pp.61-67.

DOI: 10.1016/s0272-8842(98)00002-9

[3] J.H. Kim, Y.S. Lee, D.J. Kim, N.S. Park and S.I. Moon: Evaluation of Thermal ShockStrengths for Graphite Materials Using Laser Irradiation Method, Proceeding of the Thirteenth International Conference on the Strength of Materials (ICCM-13) Vol. 118 (2003).

[4] Y.S. Lee, J.H. Kim, H.S. Kim and S.H. Koo: Thermal Shock Analysis of the Nozzle Structures Under High Temperature Gradient, International Joint Symposium Between Chung-Nam National University and Beijing University of Chemical Technology Vol. 1 (2003).
