Structural Design, Manufacturing, and Wind Tunnel Test of a Small Expandable Wing

Abstract:

This paper describes design, manufacturing, and wind tunnel test of a motor-driven small-scale expandable wing for MAV class vehicles. The bird-like expandable wing has been developed for investigating the influence of aspect ratio change on the lift and drag of the wing. As a typical bird wing, the wing is separated into inner and outer wings. The wing model consists of the linkage system made of carbon composite strip/rod and the remaining part covered with carbon composite sheet and multiple LIPCAs (Lightweight Piezo-Composite Actuators) mimicking wing feathers. The LIPCA actuator was used to control wing camber, which created additional lift. Wind tunnel tests were conducted to investigate the changes in lift and drag during wing folding and expansion, and to observe the influence of LIPCA actuation on the wing. In the tests, effects of the wing fold/expansion and actuation of LIPCA on changes in lift and drag were quantitatively identified.

• Periodical: Key Engineering Materials (Volumes 306-308)
• Pages: 1157-1162
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.306-308.1157
• Online since: March 2006
• Authors: Yudi Heryawan, Hoon Cheol Park, Nam Seo Goo, Kwang Joon Yoon, Yung Hwan Byun
• Keywords: Lightweight Piezo-Composite Actuator LIPCA, MAV, Morphing Wing, Wind Tunnel Test

References

[1] Mc Gowan, A.M., Washburn, A.E., Horta, L.G., Bryant, R.G., Cox, D.E., Siochi, E.J., Padula, S.L., and Holloway, N.M., Recent Results from NASA's Morphing Project, SPIE Paper No. 4698-11, presented at the 9 th Annual International Symposium on Smart Structures and Materials, March 17-21, (2002).

DOI: 10.1117/12.475056

[2] Neal, D.A., Good, M.G., Johnston, C.O., Robertshaw, H.H., Mason, H., and Inman, D.J., Design and Wind-Tunnel Analysis of a Fully Adaptive Aircraft Configuration, AIAA Paper 2004-1727, (2004).

DOI: 10.2514/6.2004-1727

[3] Mueller, T.J., Fixed and Flapping Wing Aerodynamics for Micro Air Vehicle Applications, American Institute of Aeronautics and Astronautics Inc, Vol. 195, pp.115-139, (2001).

DOI: 10.2514/4.866654

[4] Yoon, K.J., Shin, S.J., Park, H.C., and Goo, N.S., Design and manufacture of a lightweight piezo-composite curved actuator, Smart Materials and Structures, 11 (2002), pp.163-16.

DOI: 10.1088/0964-1726/11/1/401

[5] Wright, W., Wright, O., Chanute, O., and Wilks, M., The Papers of Wilbur and Orville Wright: including the Chanute-Wright letters and other papers of Octave Chanute, McGraw Hill Press, (2001).

DOI: 10.2307/1842810

[6] Wilson, C.E., and Sadler, J.P., Kinematics and Dynamics of Machinery, Pearson Education, Inc, (2003).

[7] Suhariyono, A., Kim, J.H., Hwang, H.C., Goo, N.S., Park, H.C., and Yoon, K.J., Design of Aerodynamic Performance Measurement System for Micro Air Vehicles (MAV), Proceeding of the KSAS Conference, November 18-19, (2004).

[8] Anderson, J.D., Fundamentals of Aerodynamics, McGraw Hill Press, (1991).

[9] DesignFOIL ®, http: /www. dreesecode. com.

[10] Alexander, D.E., Nature's Flyers, The John Hopkins University Press, (2002).
