Thermal Characteristics of the Headstock System on the NC Precision Lathe

Abstract:

High speed and high quality precision are essential requirements of NC lathes in modern industry. Since the heat generated from headstock system is a major factor causing machining inaccuracy, in this work, the thermal 3D model of the headstock system is built and its thermal characteristics are investigated using FEM. From the comparison of the numerical results with the experiment results, it is found that the FEM predicted well the thermal characteristics of the headstock system and the model is reliable to further optimum design of the headstock system.

• Periodical: Key Engineering Materials (Volumes 315-316)
• Pages: 164-168
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.315-316.164
• Online since: July 2006
• Authors: C. Guo, Qing Hong Sun
• Keywords: Finite Element Model (FEM), Headstock System, NC Lathe, Thermal Characteristic

References

[1] V.A. Krunglov: Vestnik Mashinostroeniya, Vol. 63 (1983), pp.49-52.

[2] T.Y. Chen, W.J. Wei and J.C. Tsai: International Journal of Machine Tools & Manufacture, Vol. 39 (1999), p.1961-(1977).

[3] D.A. Krulewich: Mechatronics, Vol. 8 (1998), pp.395-412.

[4] J.K. Choi and D.G. Lee: International Journal of Machine Tools & Manufacture, Vol. 38 (1998), pp.1017-1030.

[5] J.F. Tu and J. L. Stein: Proceedings of the American Control Conference, Baltimore, MD, (1994).

[6] Y.Q. Liang: Heat Transfer and Thermal Deformation in Manufacture (China Machine Press, China 1982)�.

[7] S. Dai: Application Handbook of Rolling bearings in Machine Tools (China Machine Press, China 1993)�.

[8] H. Shen: Handbook of Mechanical Engineering (China Machine Press, China 1982), Vol. 2. �.

[9] S. Gao, L.J. Zeng, C.Y. Y, L. Zheng and P.Q. Ye: ACTA Metrological Sinica, Vol. 22 (2001), pp.1-6. �.
