Domain Wall Engineering in Potassium Niobate Single Crystals and Their Piezoelectric Properties

Abstract:

For potassium niobate (KNbO3) single crystal, the 31 resonators with the highest piezoelectric constant d31 were designed using transformation of axis. We confirmed that the engineered domain configurations with maximum d31 of –55.1 pC/N was caused by a combination between two polarization with polar directions along [101]c and [-101]c directions. Moreover, if there are larger piezoelectric constants from domain wall region, we can expect the much higher piezoelectric properties. To induce the above domain configuration, a new poling method using patterning electrode was investigated. In this study, the two methods on the basis of temperature-induced phase transition at 207 °C and electric-field-induced phase transition at room temperature were investigated.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 320)

Pages:

147-150

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.320.147

Citation:

Cite this paper

Online since:

September 2006

Authors:

Keisuke Yokoh, Song Min Nam, Hirofumi Kakemoto, Takaaki Tsurumi, Hirohiko Kumagai, Satoshi Wada

Keywords:

Domain Wall, Engineered Domain Configuration, Patterning Electrode, Piezoelectric Constant, Potassium Niobate, Single Crystal

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] B. Jaffe, W. R. Cook, Jr. and H. Jaffe: Piezoelectric Ceramics (Academic Press, New York, 1971), p.135.

Google Scholar

[2] S. -E. Park and T.R. Shrout: Mater. Res. Innov. 1 (1997), p.20.

Google Scholar

[3] S. Wada, K. Yako, H. Kakemoto and T. Tsurumi: J. Appl. Phys., 98 (2005) p.14109.

Google Scholar

[4] S. Wada, K. Muraoka, H. Kakemoto, T. Tsurumi and H. Kumagai: Jpn. J. Appl. Phys., 43 (2004), p.6692.

Google Scholar

[5] J. Hirohashi, K. Yamada, H. Kamio, and S. Shichijyo: Jpn. J. Appl. Phys., 43 (2004), p.559. e-mail: swda@ceram. titech. ac. jp , Fax: 03-5734-2514.

Google Scholar
