Damage Detection in CFRP Bonded Structures by Using Fiber Bragg Grating Sensors as Ultrasonic Wave Receivers

Abstract:

The authors developed a damage detection system that generates ultrasonic waves with a piezo-ceramic actuator and receives them by a fiber Bragg grating (FBG) sensor. In this research, this system was applied to evaluate debonding progress in CFRP skin/stringer bonded structures. FBG sensors were bonded on the stringer or embedded in the adhesive layer. Then, ultrasonic wave at 300kHz was propagated through the debonded region, and the wavelet transform was applied to the received waveform. After that, a new damage indexand a correlation coefficient were calculated from the distribution of the wavelet transform coefficient. As a result, the damage index increased and the correlation coefficient decreased with an increase in the debonded area. Hence the length of the debonding between the skin and the stringer could be well evaluated.

You might also be interested in these eBooks

Advances in Composite Materials and Structures

View Preview

Info:

Periodical:

Key Engineering Materials (Volumes 334-335)

Pages:

1137-1140

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.334-335.1137

Citation:

Cite this paper

Online since:

March 2007

Authors:

Nobuo Takeda, Y. Okabe, J. Kuwahara, Toshimichi Ogisu, Seiji Kojima

Keywords:

Carbon Fiber Reinforced Polymer/Plastic (CFRP), FBG Sensor, Health Monitoring, Skin/Stringer Structure, Ultrasonic Wave (UW)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] T. Ogisu, M. Shimanuki, S. Kiyoshima, Y. Okabe and N. Takeda, in Smart Structures and Materials 2005, Proceedings of SPIE Vol. 5758, edited by E. Udd and D. Inaudi, SPIE (2005), p.93.

DOI: 10.1117/12.598085

Google Scholar

[2] N. Takeda, Y. Okabe, J. Kuwahara, S. Kojima and T. Ogisu: Compos. Sci. Technol. 65 (2005), p.2575.

Google Scholar
