FEM Simulation and Experimental Test on Residual Stress of Cold Expansion Hole of Rectangular Plate

Abstract:

A 2D rectangular plate model has been established to study the residual stress fields of cold expansion hole. Experiments were carried out to measure the residual stress of cold expansion hole and verify simulation results. The FEM results show, with interference values developing, the maximum values of circumferential residual compressive/tensile stress increase and higher positive stress values are obtained at the boundary of the rectangular plate. However, higher positive stresses at the boundary of plate are harmful to the capacity of fatigue resistance, the determinations of best interference value to a certain wide plate were proposed. Finally, the effect of the plate width on the residual stress distribution was analyzed.

• Periodical: Key Engineering Materials (Volumes 348-349)
• Pages: 745-748
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.348-349.745
• Online since: September 2007
• Authors: Xiao Jun Shao, Jun Liu, Yong Shou Liu, Zhu Feng Yue
• Keywords: Cold Expansion, Experimental Test, Interference Value, Residual Stress

References

[1] H.F. HUANG, H. YAN and C.H. TAO: J. Mechanical Strength. 20(1998), p.237.

[2] P.F.P. de Matos, P.M.G.P. Moreira, P.P. Camanho and P.M.S.T. de Castro: Finite Elements in Analysis and Design . 41 (2005), p.989.

DOI: 10.1016/j.finel.2005.01.001

[3] J. T. Maximov, A. P. Anchev: Machine Tools ＆ Manufacture. 43(2003), p.1241.

[4] M. Priest, C.G. Poussard, M.J. Pavier and D.J. Smith: Exp. Mech. (1995), p.361.

[5] P. Papanikos, S.A. Meguid: Mater. processing Technol. 92(1999), p.424.
