R&D of Ray Tracing Simulation Software and Fabrication Technologies Based on VCAD (Volume-CAD) Concept for GRIN Lens

Abstract:

We have been developing an intellectual manufacturing process applying IT (V-Cam system fabrication processes) based on Volume-CAD (VCAD) system which can express internal information of materials. This paper introduces the ultra-precision grinding, ray tracing (optical path) simulation software ‘V-Opt’ and the measurement of actual optical functions in the development of optical element taking gradient refractive index (GRIN) lens with functionally graded material properties as a model. In finish ground GRIN lens using SD#8000 wheel, the P-V (Peek to Value) of 27.07 nm, surface roughness (Ra) of 1.83 nm is obtained. ‘V-Opt’ developed for GRIN lens have two main functions; one is the visualizations of ray tracing and the other is the evaluation of spot diagram and focal length.
