Fractographic Investigations of Ordinary Ceramic Refractory Materials with Reduced Brittleness

Abstract:

A fractographic procedure was developed and applied for ordinary ceramic refractory materials with a rather large size of heterogeneities and defects. It is based on a stereooptical method for generation of digital surface profiles which are evaluated by an autocorrelation function. Furthermore, a lateral correlation length is derived. A group of seven refractory materials was characterised by mechanical and fracture mechanical investigations, and the same specimens had been characterized by the fractographic procedure. Correlations have been tested. The results show a relation between the lateral correlation length and two fracture mechanical characteristics which are significant for the material brittleness and the elastic strain energy stored at maximum load. These relations are contributed to the dependence of the crack path on brittleness. With decreasing brittleness the amount of the crack path proceeding along the grain/matrix boundary increases for the materials investigated.

• Periodical: Key Engineering Materials (Volume 409)
• Pages: 209-215
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.409.209
• Online since: March 2009
• Authors: Harald Harmuth, Christian Manhart
• Keywords: Fractography, Fracture Mechanic, Fracture Testing, Refractory, Wedge Splitting Test

References

[1] H. Harmuth and E.K. Tschegg: Fatigue Fract. Eng. Mater. Struct. Vol. 20 (1997), p.1585.

[2] R.C. Bradt: Ceramic Bulletin Vol. 67 (1988), p.1176.

[3] M. Sakai: Taikabutsu Overseas Vol. 8 (1988), p.4.

[4] J.J. Uchno, R.C. Bradt and D.P.H. Hasselman: Ceramic Bulletin Vol. 55 (1976), p.665.

[5] E.K. Tschegg, Austria Patent Specification AT 390 328. (1986).

[6] E.K. Tschegg: Materialprüfung Vol. 33 (1991), p.338.

[7] H. Harmuth, K. Rieder, M. Krobath and E. Tschegg: Mater. Sci. Eng. A Vol. 214 (1996), p.53 Fig. 4. Parameters RS, P∆q and DS for the materials A to C of Table 1.

[8] D.P.H. Hasselman: J. Am. Ceram. Soc. Vol. 52 (1969), p.600.

[9] Information on http: /www. alicona. com.

[10] E.E. Underwood and K. Banerji, in: Metals Handbook.

[11] C. Manhart and H. Harmuth, in: Optical 3-D Measurement Techniques VIII, edited by A. Grün/H. Kahmen, ETH Zürich, Vol. 2, pp.207-212 (2007).

[12] G.E. Box and G.M. Jenkins: Time Series Analysis: Forecasting and Control (Englewood Cliffs, NJ, Prentice-Hall 1976).

[13] I. Simonovski, M. Kovaè and L. Cizelj: Mater. Sci. Eng. A Vol. 381 (2004), p.273.

[14] Ch. Manhart: Fraktographische Untersuchungen an basischen feuerfesten Baustoffen unterschiedlicher Sprödigkeit (Thesis, University of Leoben 2007).

[15] European standard EN ISO 4287 (1997).
