The Design and Manufacture of Quick-Point Grinding Wheel

Abstract:

It is important that preparing high quality grinding wheel to match Quick-point grinding processing. Using brazed CBN grinding wheel, grains can be combined with wheel matrix in high bonding strength, which is helpful to minimize wheel wear and to gain a good grinding ability. By establishing the connection between stress and its increment, the mechanical properties of wheel under different conditions is described. The wheel speed has effect on wheel matrix displacement and stress. Applying finite element method to optimize wheel structure, a final grinding wheel for Quick-point grinding is obtained.

• Periodical: Key Engineering Materials (Volume 416)
• Pages: 365-369
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.416.365
• Online since: September 2009
• Authors: Jian Qiu, Ya Dong Gong, Yue Ming Liu, Yan Cheng Zhang
• Keywords: Design of Grinding Wheel, Finite Element Analysis (FEA), Quick-Point Grinding, Section of Grinding Wheel, Strength Check

References

[1] S.C. Xiu, G.Q. Cai and Y.D. Gong: China Mechanical Engineering, Vol. 16 (2005), p. (2086).

[2] S.Y. Zhang: Handbook of Metal Materials (China Science and Technology Culture Press, HongKong 2005).

[3] Z.L. Xu: Elastic Mechanics (High Education Press, China 2003).

[4] R.J. Ong, J.T. Dawley and P.G. Clem: Submitted to Journal of Materials Research (2003).

[5] Akinori Yui , Hwa-Soo Lee: Journal of Materials Processing Technology, Vol. 62 (1996), p.393.

[6] M.J. Jackson, C.J. Davis, M.P. Hitchiner and B. Mills: Journal of Materials Processing Technology, Vol. 110 (2001), p.78.
