The Grinding Mechanism on Quick-Point Grinding Wheel Wear and Effects on Surface Quality

Abstract:

A study on the wear of Quick-point grinding wheel was carried on. The wheel wear was found having great influence on grinding performance and grinding quality. After analyzed the wear process and mechanism in Quick-point grinding, it was found the wear rate was directly related to some factors such as wheel width, workpiece speed, feed rate and Quick-point grinding angle, and it was indirectly affected by wheel speed and cutting depth. By means of some wear criteria, the wheel wear was able to be predicted. Furthermore, a wear model in wheel’s accurate area has been built up.

• Periodical: Key Engineering Materials (Volume 416)
• Pages: 370-374
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.416.370
• Online since: September 2009
• Authors: Ya Dong Gong, Jian Qiu, Yu Jiao Liu, Jun Cheng, Fan Xu
• Keywords: Inclined Grinding Wheel, Influence Factor, Quick-Point Grinding, Wear Process, Wheel Wear Model

References

[1] E. Junker: QUICKPOINT-Everything in One Clamping (Erwin Junker Maschinenfabrik GmbH, Germany 2004).

[2] W. Lortz: Wear 53 (1979), pp.115-128.

[3] J.X. Ren: Grinding Principle (Northwestern Polytechnical University Publishers, China 1988).

[4] R. Neugebauer, K. -U. Hess, S. Gleich and S. Pop: International Journal of Machine Tools & Manufacture, Vol. 45 (2005) No. 10, pp.1120-1123.

DOI: 10.1016/j.ijmachtools.2005.01.002

[5] S. Malkin: Grinding Technology Theory and Applications of Machining with Abrasives (Ellis Horwood, Chichesler 1989).

[6] A.J. Pekelharing, J. Verkerk and F.C. Van Beukering: New Developments in Grinding (M.C. Shaw/Carnegie Publishing, Pittsburgh, PA 1972).

[7] A. Hassui, A.E. Diniz, J.F.G. Oliveira and J.J.F. Gomes: Wear, Vol. 217 (1998) No. 1, pp.7-14.

[8] H. Yoshikawa: Annals of the CIRP, Vol. 4 (1977).
