High Efficient Mechanism of Material Removal in Two-Dimensional Ultrasonic Grinding from the Locus Perspective

Abstract:

Relative motion of single abrasive is analyzed for the different applied directions of longitudinal ultrasonic vibration, and its locus is simulated in the present paper. The research results show that the locus in two-dimensional ultrasonic vibration is only similar to that in y-direction, and both are close to sinusoid curves. The width of grooves scratched by abrasive grains y-direction (axial direction of grinding wheel) is two times of the vibration amplitude, and the material removal rate increases remarkably. In case of x-direction (tangential direction of grinding wheel) ultrasonic vibration, abrasive grains with periodic force impact material surface with high frequency vibration, which make material fracture removal easy. Therefore, the high efficiency essence of material removal in two-dimensional ultrasonic grinding is revealed in view of locus. In addition, according to the results of grinding experiments, under same conditions good surface quality can be obtained in two-dimensional ultrasonic grinding and material removal rate in common grinding is the lowest. Consequently it is further proved that the method of two-dimensional ultrasonic vibration grinding is an effective one for ceramic materials.

• Periodical: Key Engineering Materials (Volume 416)
• Pages: 609-613
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.416.609
• Online since: September 2009
• Authors: Ming Li Zhao, Bo Zhao, Yu Qing Wang, Guo Fu Gao
• Keywords: Abrasive Locus, Ceramic Material, Ultrasonic Grinding

References

[1] R.D. Han: ew modern machining technology (Electronic Industry Press, China 2003).

[2] S.Y. Yu and B. Lin. Progress of Advanced-ceramic Machining Technology. Diamond & Abrasives Engineering, Vol. 124 (2001), pp.36-40.

[3] B.M. Li and B. Zhao: Modern Grinding Technology (Machinery Industry Press, China 2003).

[4] B. Zhao: Study on Honing System Provided with Axial Ultrasonic Vibration and the Feature of Cutting Hardness and Brittle Materials in ductile Domain (Ph.D. Dissertation, Shanghai Jiao Tong University, China 1999), pp.85-88.

[5] M.L. Zhao: Study on Polishing Technology of Engineering Ceramics Ultra-precise Plate (Henan Polytechnic University, China 2007), pp.40-52.
