Fretting Damage of Contact Interfaces of CMSX 4 with and without T800 Coating

Abstract:

Fretting fatigue is a complex phenomenon that occurs at component interfaces undergoing low amplitude oscillation and high contact pressure. In turbomachinery fretting occurs also at the blade tip interfaces where shrouds are machined with the aim to reduce the blade resonant vibration amplitude. The aim of this study is to investigate the damage by fretting on CMSX4 superalloy interfaces with and without plasma sprayed T800 coating. The contact pair is a hemispherical surface on a flat surface. The hysteresis cycles, namely the contact force against the relative displacement, have been measured through the experiment. The worn surfaces have been characterized by three-dimensional optical interferometry and SEM analysis. After 3×106 and 10×106 fretting cycles the surface without coating shows surface cracks and large change in the contact parameters.

• Periodical: Key Engineering Materials (Volumes 417-418)
• Pages: 553-556
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.417-418.553
• Online since: October 2009
• Authors: Mario Lavella, Daniele Botto, Muzio M. Gola
• Keywords: CMSX4, Coating, Fretting Fatigue

References

[1] C.R. Gagg and P.R. Lewis: Engineering Failure Analysis Vol. 14 (2007), p.1618.

[2] J. M Gallardo, J.A. Rodriguez and E. J Herrera: Wear Vol. 252 (2002), p.264.

[3] J.H. Griffin: Int. J. of Turbo and Jet Engines Vol. 7 (1990), p.297.

[4] C. Navas, M. Cadenas, J.M. Cuetos and J. de Damborene: Wear Vol. 260 (2006), p.838.

[5] M.J. Tobar, J.M. Amado, C. Álvarez, A. García, A. Varela and A. Yáñez: Surf. Coat. Technol. Vol. 202 (2008), p.2297.

[6] C.H. Hager Jr, J.H. Sanders and S. Sharma: Wear Vol. 257 (2004), p.167.

[7] S. Fouvry, P. Duó and Ph. Perruchaut: Wear Vol. 257 (2004), p.916.

[8] C.H. Hager Jr, J.H. Sanders and S. Sharma: Wear Vol. 265 (2008), p.439.

[9] C.H. Hager Jr, J.H. Sanders, S. Sharma and A. Voevodin: Wear Vol. 263 (2007), p.430.
