Structural Design and the State of Motion Analyzes for Multi-Degree-of-Freedom Electro-Hydraulic Mix-Drive Motion Simulator

Abstract:

This paper has designed a multi-degree-of-freedom electro-hydraulic mix- drive motion simulator, which could move and turn spatially. It has both the advantages of the parallel turnplate and the series turnplate. The homogeneous coordinate transformation matrix was used to analyze the simulator’s state of motion. The position and attitude matrix for describing the simulator movement has been obtained. The kinematics equation for showing the relation of the positions between hydraulic drive rod and the turnplate was given, thus provided the theory basis for the further research to the simulator.

• Periodical: Key Engineering Materials (Volumes 419-420)
• Pages: 169-172
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.419-420.169
• Online since: October 2009
• Authors: Yue Fa Zhou, Xiang Chun Ji, Hong Liang Li, Zhao Kui Zhang
• Keywords: Coordinate Transformation, Kinematics, Motion Simulator, Parallel Turnplate, Series Turnplate

References

[1] D. Stewart: A platform with six degree of freedom, in Proceedings of the Institution of Mechanical Engineering, Vol. 180(1965), No. 5, Part 1, pp.371-386.

[2] Burns G C, et al: Space Station Full-Scale Docking-Berthing Mechanisms Development, Vol. 2(1998), pp.51-56.

[3] Hinmon E M, Bushman D M: Soviet Automated Rendezvous and Docking System Overview, Vol. 5(1991), pp.22-24.

[4] Aul, Raymond J.; Remley, William E.; Scher, Robert M.; Sibenaller, Henry F: LNG ship motion simulator and platform. Society of Naval Architects and Marine Engineers - Transactions 2007, Vol. 114, pp.128-139.

[5] Tran, Due T.; Schroeder, Jeffery A: Rotorcraft research at the NASA vertical motion simulator。 AHS International 64th Annual Forum, Proceedings, Vol. 3(2008), pp.2390-2402.

[6] Teufel, H.J.; Nusseck, H. -G.; Beykirch, K.A.; Butler, J.S.; Kerger, M.; Bulthoff, H. H: MPI motion simulator: development and analysis of a novel motion simulator. Collection of Technical Papers - 2007 AIAA Modeling and Simulation Technologies Conference, Vol. 1(2007).

DOI: 10.2514/6.2007-6476

[7] Peterson, Robert; Novokov, Mikhail; Hsu, Jeffrey; Gass, Herb; Benson, Michael: 6 DOF high-frequency motion simulator Phase II. Proceedings of SPIE - The International Society for Optical Engineering, Vol. 4717(2002), pp.56-67.

DOI: 10.1117/12.474707

[8] Yu, Da-Yong; Cong, Da-Cheng; Han, Jun-Wei: Accuracy analysis of motion simulator of docking mechanism. Harbin Gongye Daxue Xuebao/Journal of Harbin Institute of Technology, Vol. 40(2008), No. 2, pp.264-268.
