The Structural Design and Optimization for the Inner-Frame of Subsea Flange Connection Tool

Abstract:

Subsea Flange Connection Tool (SFCT) is a remote apparatus for connecting underwater bolted flanges, especially applied in the offshore pipeline laying. As a pivotal unit construction of SFCT, Inner-frame enables the Bolt Handling Tool and Nut Handling Tool to move separately in axial direction and together in circumferential direction with the reference of the pipe’s axes. This paper presents the Inner-frame’s structural concept and builds its kinematics-equivalent mechanism models, carrying on the kinematics analysis of Inner-frame; to improve the energy efficiency, models the Inner-frame’s rotation-mechanism parametrically and establishes an objective with the minimum power consumption, which generates the optimal positions for the hinged-hydraulic cylinder’s joints with Box and Pendulum.

• Periodical: Key Engineering Materials (Volumes 419-420)
• Pages: 197-200
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.419-420.197
• Online since: October 2009
• Authors: Zhi Gang Li, Qiu Hong Lin, Dong Yan Zhao, Li Quan Wang
• Keywords: Centering Alignment, Design, Flange Connection Tool, Minimize Power Consumption, Optimization, Parametrical Model

References

[1] Information on http: /www. mexico-china. cn/html/200707/27/091604846. htm.

[2] Giovanni Corbetta, David S. Cox: Offshore Europe Conference Vol. 2 (1999), p.3.

[3] Stolt Offshore Limited: Offshore Technology (2002), p.29.

[4] Jian-Rong Zheng: Virtual Prototyping Technology and Introduction to Improve (Mechanical Industry Press, China 2002).

[5] Wang Li-quan, Lin Qiu-hong and Chen Dong-liang, CN Patent 200810064661. 5. (2008).
