Optimization Design of Pressure Shell in Underwater Vehicle Based on Response Surface Model

Abstract:

Cylinder shell stiffened by rings is used commonly in submersibles, and structure strength should be verified in the initial design stage considering the thickness of the shell, the number of rings, the shape of ring section and so on. Based on the statistical techniques, a strategy for optimization design of pressure hull is proposed in this paper. Its central idea is that: firstly the design variables are chosen by referring criterion for structure strength, then the samples for analysis are created in the design space; secondly finite element models corresponding to the samples are built and analyzed; thirdly the approximations of these analysis are constructed using these samples and responses obtained by finite element model; finally optimization design result is obtained using response surface model. The result shows that this method that can improve the efficiency and achieve optimal intention has valuable reference information for engineering application.

• Periodical: Key Engineering Materials (Volumes 419-420)
• Pages: 89-92
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.419-420.89
• Online since: October 2009
• Authors: Zhuo Yi Yang, Yong Jie Pang, Zai Bai Qin
• Keywords: Cylinder Shell Stiffened by Rings, Finite Element, Optimization Design, Response Surface Model, Strength Analysis

References

[1] Liu Tao: Analysis and Design of Deep-Sea Submersibles Structures. PHD thesis, China Ship Scientific Research Center (2001).

[2] Chen Meixia, Jin Baoyan and Chen Lejia: Ship Science and Technology. Vol. 30-3 (2008), p.64.

[3] Simpson TW, Lin K J and Chen W: International Journal of Reliability and Applications. Vol. 2-3(2001), p.209.

[4] Zhang Chengcheng and Yao Weixing: Transactions of Nanjing University of Aeronautics and Astronautics. Vol39-1(2007), p.37.

[5] Chen Baolin: Optimal Theory and Algorithm (Tsinghua University Press, Beijing 2005).
