High Voltage Breaker Cam Actuator’s Optimization Design on the Virtual Prototype Technology

Abstract:

In this paper, the virtual prototype technology is used for the analyzing and optimizing high voltage breaker actuator’s cam machine. While the high voltage breaker closing, the moving contactor can have the perfect dynamic property by the optimal data. The contactor’s dynamic property curve should be in line with perfect dynamic property curve. The velocity curve can be gotten by analyzing virtual prototype. According to the theory of high voltage breaker’s dynamic property, a smooth voltage curve can be fitted. This fitting curve as the perfect voltage curve can be used for optimizing the cam machine. Supposing other work condition is invariable, the key points on cam profile which decide the dynamic property of the cam machine are analyzed. The coordinates of the key points are optimized and the cam profile is amended. Analyzing the dynamic property of the breaker’s virtual prototype with the amended cam machine, the contactor’s dynamic property curve is perfect. In this paper, the optimal coordinates of the key points are used on the cam profile, and the high voltage breaker actuator’s cam machine is optimal.

• Periodical: Key Engineering Materials (Volumes 419-420)
• Pages: 97-100
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.419-420.97
• Online since: October 2009
• Authors: Jing Qiu Tang, Yan Bin Cui
• Keywords: CAM, Dynamic Propertry, Optimization, Velocity Curve, Virtual Prototyping Technology

References

[1] Yuan Shun: High Voltage Breaker Spring Actuator. Beijing: China Machine Press, (2001).

[2] Yuan Shun: Simulation and Optimization of the Spring Actuator for Vacuum Circuit Breaker. Beijing: China Electric Power Press, (1997).

[3] Wang Ji-mei: The research and development of the large capacity vacuum generator circuit breakers. Xi'an: Xi'an Jiao Tong University Press, 2001. 10 212-218.

[4] Cui Yan-bin: New Actuator Open Velocity Analysis. Henan: Journal of Mechanical Transmission. 2002(04) 17-18.

[5] Tang Jing-qiu: Design of Cam Mechanism with Variable Driving Speed Based on Energy Method. Tianjin: Journal of Machine Design. 2005. 9 54-57.

[6] Xu Guo-zheng: High Voltage Breaker Principle and Application. Beijing: Qinghua University Press, (2000).

[7] Chen Li-ping: Dynamics Analytical of Mechanical System and ADAMS Application Tutorial. Beijing: Qinghua University Press, 2005. 1.

[8] Li Zeng-gang: Introduction and Example of ADAMS. Beijing: National Defense Industry Press, (2006).

[9] He Qing-fang: Product Design and Mechanism Dynamics Analysis. Beijing: China Machine Press, 2004. 8. 26.

[10] Zheng Jian-rong: ADAMS-Virtual Prototype Technology Introduction and Development. Beijing: China Machine Press, (2004).
