Numerical Analysis of Four-Hole Extrusion of Aluminum Alloys

Abstract:

The work presents the results of FEM simulations of extrusion process with the use of four – hole dies of various geometry. The traditional flat dies and pocket dies were adopted for comparison. The calculations were conducted for indirect extrusion of rods of 14 mm in diameter from the 6061 aluminium alloy. The distributions of strains, stresses, metal velocities and temperature within the deformation zone were the basis for metal flow analysis. Based on the conducted calculations the die configuration, leading to the best product quality was recommended. The product quality was evaluated by the flow direction of rods from the die orifices.

You might also be interested in these eBooks

Advances on Hot Extrusion and Simulation of Light Alloys

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 424)

Pages:

173-179

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.424.173

Citation:

Cite this paper

Online since:

December 2009

Authors:

W. Libura, Artur Rękas, Dariusz Lesniak

Keywords:

Aluminium Alloy, Extrusion, Four-Hole Die, Metal Flow, Numerical Calculation

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] W. Libura: Metal flow in extrusion, in Metallurgy on the turn of the 20th century, Krakow, AKAPIT Publication, (2002) pp.391-412.

Google Scholar

[2] K. Nakanishi, S. Kamitani, T. Yang. H. Takio, M. Nakayoshi: Material flow characteristics in hot extrusion of aluminium alloy controlled by the flow guide and die bearing, Proc. 7 th ICTP, vol. 1 (2002) pp.409-414.

Google Scholar

[3] Y. T. Kim, K. Ikeda, T. Murakami: Metal flow in porthole die extrusion of aluminum, Journal of Materials Processing Technology, vol. 121 (2002) pp.107-115.

DOI: 10.1016/s0924-0136(01)01215-8

Google Scholar

[4] W. Libura, D. Leśniak, A. Rękas, J. Zasadziński: Physical and numerical modelling of extrusion of flat sections from hard deformable aluminium alloys, Proc. of the 8th International Conference on Technology of Plasticity ICTP, Verona (2005).

Google Scholar

[5] W. Libura: Płynięcie metalu w procesie wyciskania, AGH University of Science and Technology Publications, Kraków 2008 (in Polish).

Google Scholar

[6] Z. Peng, T. Sheppard, Effect of die pockets on multi-hole extrusion, Materials Science and Engineering, A 407 (2005) pp.89-97.

DOI: 10.1016/j.msea.2005.06.048

Google Scholar
