Contact Stress Analysis of NCD Coating on Cemented Carbide

Abstract:

The contact stress of cemented carbide with NCD coating in elastic contact was analyzed using ANSYS. Factors such as elastic modulus and thickness of NCD film and elastic modulus of interlayer which affect the shear stress distribution of NCD film on cemented carbide substrate were investigated. The results show that the maximum shear stress point moves towards the interface with the increase of film elastic modulus. Film thickness has a significant effect on shear stress distribution of NCD film. High shear stress develops in the film layer with the increase of film thickness. Interlayer with low elastic modulus will cause shear stress concentration in NCD film.

• Periodical: Key Engineering Materials (Volumes 431-432)
• Pages: 98-101
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.431-432.98
• Online since: March 2010
• Authors: Jia Jing Yuan, Wen Zhuang Lu, Dun Wen Zuo, Feng Xu
• Keywords: Contact Analysis, Finite Element Model (FEM), NCD Film, Shear Stress

References

[1] H. Itoh, S. Lee, K. Sugyama and et al: Surface and Coatings Technology, Vol. 112 (1999), pp.199-203.

[2] F. Xu, D. Zuo, W.Z. Lu and et al: Acta Metallurgica Sinica, Vol. 44 (1) (2008), pp.74-78(in Chinese).

[3] W.Z. Lu, D. Zuo, W. Min and et al: Mechanical Engineering, Vol. 146(8) (2003), pp.7-9 (in Chinese).

[4] H. Djabella and R.D. Arnell: Thin Solid Films, Vol. 213 (1992), pp.205-219.

[5] D. Diao and K. Kato: Thin Solid Films, Vol. 245 (1994), pp.115-121.

[6] P.G. Kosky and T.R. Anthony: Diamond and Related Materials, Vol. 5 (1996), pp.1313-1357.

[7] J.G. Li, D.P. Hu, M. Jun and et al.: Acta Metallurgica Sinica, Vol. 42(7) (2006), pp.763-769(in Chinese).
