Touch-Trigger Measurement of Micro-Cavity by Optical Fiber Coupling

Abstract:

In order to measure the geometric dimension of a micro-cavity, a touch-trigger measurement method is proposed, in which the light coming from the incident optical fiber is transmitted in the reversal direction via the optical fiber coupling into the effluent optical fiber, the lateral displacement of the touch-trigger sensor is transformed into the deflexion of light coming out from the effluent optical fiber, and the deflexion is transformed into an image signal by the object lens and CCD capturing system. The effectiveness of the proposed method is verified by experiments. Experimental results indicate that the proposed method can be used to measure the geometric dimension of a micro-cavity. A blind hole of 1.5 mm deep and about 0.2 mm in diameter is measured with the touch-trigger sensor and self-developed micro-hole diameter measuring machine with a repeatability uncertainty of less than 0.2 m.

• Periodical: Key Engineering Materials (Volume 437)
• Pages: 174-178
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.437.174
• Online since: May 2010
• Authors: Ji Wen Cui, Chuan Xi Song, Jiu Bin Tan
• Keywords: Measurement of Micro-Cavity, Optical Fiber Coupling, Reversal Transmission

References

[1] Jiubin Tan: Some Major Concern Questions in the Research of Super Precision Measuring Technique and Instrument Engineering. China Mechanical Engineering (2000).

[2] M. Yamamoto, H. Takeuchi, S. Aoki: Dimensional Measurement of High Aspect Ratio Structures with a Resonating Micro Cantilever Probe. Microsystem Technologies (2000).

DOI: 10.1007/s005429900037

[3] H. Schwenke, F. Waldele, C. Weiskirch, et al: Opto-tactile sensor for 2D and 3D measurement of small structures on coordinate measuring machines. CIRP Ann Manuf Technolog (2001).

DOI: 10.1016/s0007-8506(07)62140-4

[4] Ulrich Neuschaefer-rube, Michael Neugebauer, Wiebke Ehrig, et al: Tactile and Optical Microsensore - Test Prcedures and Standards. Key Engineering Materials (2007).

DOI: 10.4028/www.scientific.net/kem.381-382.23

[5] B. Muralikrishnan, J. Stone, S. Vemuri, et al: Fiber Deflection Probe for Small Hole Measurement. In: Proceedings of the ASPE Annual Metting (2004).

[6] Jack A. Stone, Bala Muralikrishnan, John R. Stoup: A Fiber for CMM Measurements of Small Features. Proc. SPIE (2005).

[7] B. Muralikrishnan, J.A. Stone, J.R. Stoup: Fiber Deflection Probe for Small Hole Metrology. Precision Engineering (2006).

DOI: 10.1016/j.precisioneng.2005.07.004
