Compound Micro/Nano Machining – A Tool-Based Innovative and Integrated Approach

Abstract:

Compound micro-machining is the most promising technology for the production of miniaturized parts and this technology is becoming more and more important and popular because of growing demand for industrial products with not only increased number of functions but also of reduced dimensions, higher dimensional accuracy and better surface finish. In this paper, the development efforts in micro/nano-machining based on solid tools (tool-based micro/nano-machining) in NUS are introduced. In order to achieve meaningful implementation of micro-machining techniques, this research seeks to address four important areas; namely (a) development of machine tool capable to do both conventional micro-machining, (b) process control, (c) process development to achieve necessary accuracy and quality, and (d) on-machine measurement and inspection. An integrated effort in these areas has resulted in successful fabrication of micro-structures that is able to meet the miniaturization demands of the industry. In the area of nano-machining machine tool and process developments have also been carried out for electrolytic in-process dressing (ELID) grinding and ultra precision machining using single point and poly crystalline diamond tools to produce nano surface finish on hard and brittle materials. An ultra-precision diamond turning machine has been developed which incorporates a fast and fine tool servo system to produce nano-precision surfaces and features.

• Periodical: Key Engineering Materials (Volumes 447-448)
• Pages: 9-15
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.447-448.9
• Online since: September 2010
• Authors: Mustafizur Rahman, A.B.M.A. Asad, T. Masaki, Yoke San Wong, A. Senthil Kumar
• Keywords: Compund Micro-Machining, Diamond Turning, ELID (ELectrolytic In-Process Dressing) Grinding, Tool-Based Micro-Machining, Tool-Based Nano-Machining

References

[1] Lu, Z, T. Yoneyama, Micro cutting in the micro lathe turning system, J. of Machine Tools & Manu., V39, 1999, p.1171.

DOI: 10.1016/s0890-6955(98)00092-3

[2] Van Ossenbruggen C., Micro spark Erosio, Philips Technisch Tijdschrift, 20 (1969), p.200.

[3] Sato, T, T. Mizutani and K. Kawata, Electro-discharge machine for micro-hole drilling, National Tech. Reports, 31 (1985), p.725.

[4] Masuzawa, M., C. L Kuo and M. Fujino, Drilling of deep micro holes by EDM, Ann, CIRP, 38 (1989) p.195.

DOI: 10.1016/s0007-8506(07)62683-3

[5] Masuzawa, M., C. L Kuo and M. Fujino, A combined electrical machining process for micronozzle fabrication, Ann, CIRP, 43 (1994), p.189.

DOI: 10.1016/s0007-8506(07)62193-3

[6] Rahman, M., A S. Kumar, J.R.S. Prakash, Micro milling of pure copper, J. of Material Processing Technology, V116, 2001, p.39.

[7] Lim H.S., A. Senthil Kumar and M. Rahman, Improvement of Form Accuracy in Hybrid Machining of Microstructure, J. of Electronic Materials, Vol. 31/10, 2002, p.1032.

DOI: 10.1007/s11664-002-0039-1

[8] Schoth, A., et al, 2005, Micro wire EDM for high aspect ratio 3D microstructuring of ceramics and metals, Microsystem Technologies 11, p.250.

DOI: 10.1007/s00542-004-0399-y

[9] Zhao, W., et al, 2004, A CAD/CAM system for micro-ED-milling of small 3D freeform cavity, Journal of Materials Processing Technology, 149, p.573.

DOI: 10.1016/j.jmatprotec.2004.02.021

[10] Gianchandani Y.B., Li, T., 2006, A Micromachining Process for Die-Scale Pattern Transfers in Ceramics and Its Application to Bulk Piezoelectric Actuators, Journal of Microelectromechanical Sys., Vol. 15, No. 3, p.605.

DOI: 10.1109/jmems.2006.876667

[11] Rahman, A., et al, 2006, Development of Micropin Fabrication Process using Tool Based Micromachining, Int J of Adv. Manuf. Tech, Vol 27 (9 -10), p.939.

DOI: 10.1007/s00170-004-2270-9

[12] Yu, Z. Y., Masuzawa, T., Fujino, M., 1998, Micro-EDM for three-Dimensional cavities - Development of Uniform Wear Method -, Ann. of the CIRP, 47/1, 169-172.

DOI: 10.1016/s0007-8506(07)62810-8

[13] Murata,R., K. Okano,C. Tsutsumi, Grinding of structural ceramics, Milton C. Shaw grinding Symposium, PED-Vol. 16, 1985 pp.261-272.

[14] Ohmori, H., T. Nakagawa, Mirror surface grinding of Silicon Wafers with Electrolytic Inprocess Dressing, Ann. CIRP, 39, 1 (1990) 329-333.

DOI: 10.1016/s0007-8506(07)61065-8
