Floor-Beam Web Cutout Shape Analysis to Improve the Fatigue Resistance in Orthotropic Steel Bridge Decks

Abstract:

The modern steel orthotropic decks have been used in steel bridges for 60 years all over the world because of its super structural advantages. Recently, more bridge owners, engineers and researchers pay more attention to the fatigue problem of orthotropic steel decks for a large number of fatigue cracks found in steel bridges. For example, bridge engineers have detected hundreds of fatigue cracks in steel orthotropic deck on the 888-meter long box girder of Humen Bridge only ten years after opening to traffic. How to design or repair the fatigue details in orthotropic steel decks is the critical question to be solved at first step. In current paper, the elaborate numerical analysis model of the orthotropic steel bridge decks was developed using ANSYS software with different floor-beam web cutouts shapes, such as conventional ellipse, circular, trapezoid and Haibach web cutouts. The finite element models were calibrated by static test of one full size orthotropic steel bridge deck model. According to the analysis results, it should select the rational cutout shapes based on actual load and structural conditions in steel bridge deck design and strengthening.

• Periodical: Key Engineering Materials (Volumes 452-453)
• Pages: 161-164
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.452-453.161
• Online since: November 2010
• Authors: Chun Sheng Wang, Qin Zhang, Tao Zhang, Ya Cheng Feng
• Keywords: Fatigue, Numerical Analysis, Orthotropic Steel Bridge Deck, Static Test, Web Cutouts

References

[1] T. Gurney : Fatigue of Steel Bridge Decks. TRL State of the Art Review 8, (1992).

[2] R. Wolchuk. 1963. AISC Design Manual for Orthotropic Steel Plate Deck Bridges. Chicago: American Institute of Steel Construction Inc.

[3] Chunsheng Wang and Yacheng Feng: Review of fatigue research for orthotropic steel bridge decks. Steel Construction, Vol. 11 (2008), p.47.

[4] H. Kolstein: European research on the improvement of the fatigue resistance and design of steel orthotropic bridge decks. 2004 Orthotropic Bridge Conference, Sacramento (2004), p.25.

DOI: 10.1016/b978-008042830-7/50085-1

[5] J.R. Cuninghame and C. Beales: Fatigue crack locations in orthotropic steel decks. Remaining Fatigue Life of Steel Structures, IABSE Workshop, Lausanne(1990) , p.133.

DOI: 10.1007/978-1-4899-7232-3_41

[6] D.C. Wouter and P.V. Bogaert: Improvements to the analysis of floorbeams with additional web cutouts for orthotropic plated decks with closed continuous ribs. Steel and Composite Structures, Vol. 7 (2007), p.1.

DOI: 10.12989/scs.2007.7.1.001
