Self-Oscillation Cavity Design and Flow Field Analysis of Pipeline Supercharger

Abstract:

The self-oscillation device has many advantages and is therefore suggested to be used in the pipeline supercharger. Simulation and analysis on the pressure-increasing effect of the pipeline supercharging caused by self-oscillation cavity were carried out by finite element method. The cavity structure of self-oscillation device was designed using the fluid network theory, natural frequency calculation, resonance conditions and Large Eddy Simulation Theory. A series of flow field distribution chart of the self-oscillation cavity were obtained. Results validate that the self-oscillation device is effective to increase the pressure of the pipeline supercharger. The relation curves of pressure-increasing effect with different structure parameters of the cavity were further analyzed. Previous experimental results are accordant with the present simulation results. It shows that the numerical analyses are reliable.

• Periodical: Key Engineering Materials (Volumes 452-453)
• Pages: 177-180
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.452-453.177
• Online since: November 2010
• Authors: Zheng Yi Ren, Qing Fen Li, Xiao Li Zhao, Li Kun Li
• Keywords: Finite Element Model (FEM), Flow Field Analysis, Pipeline Supercharger, Self-Oscillation

References

[1] Chen Wei-guo: Machine Tool and Hydraulic Pressure Vol. 2 (2001), pp.54-55.

[2] Jiang Shi-quan: Theoretical and Experimental Study of New Type self-oscillation Stream Nozzle， Dissertation of Southwest Petroleum Institute (1990).

[3] Qian Sheng-hua: Numerical Simulation of Self-oscillation Cavity Flow Field, Natural Gas Industry, Vol. 6 (2004), pp.26-30.

[4] Wang Xun-ming: Numerical Simulation of Self-oscillation Device Influence Factors and Nozzle Structure Optimization Design, Transaction of Zhejiang University Vol. 9 (2005).
