Optimum Design and Numerical Simulation of Automotive Front Side-Door Impact Beam

Abstract:

In the present work, the structure optimum design and simulation analysis of automobile side-door impact beam was carried out by using Finite Element (FE) method. The model of the side-door impact beam impacting with the rigid pole was set up according to the requirement of the Federal Motor Vehicle Safety Standards intensity test of side door (FMVSS214). The numerical simulations were carried out using the software LS-DYNA. Attention was focused upon finding an optimum cross- section shape of the beam in order to improve the energy absorption character. Several types of impact beams were studied and compared. Results show that the energy absorption characters of the beam improved obviously when square cross section with the wall slope 10° and a 9 mm long curled edge was adopted.

• Periodical: Key Engineering Materials (Volumes 452-453)
• Pages: 169-172
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.452-453.169
• Online since: November 2010
• Authors: Qing Fen Li, Yan Jie Liu, Hai Dou Wang, Sheng Yuan Yan
• Keywords: Automotive Side-Door, Impact Beam, Numerical Simulation, Optimization Design

References

[1] X. Y. Zhang, X. L. Jin, Y. Y. Li, G. G. Li: Materials and Design Vol. 29 (2008), pp.403-410.

[2] National Highway Traffic Safety Administration of China: Collection of Traffic Accidentsin in China, pp.3-5 (2004).

[3] National Highway Traffic Safety Administration: Evaluation of FMVSS 214 Side Impact Protection Dynamic Performance Requirement. NHTSA Technical Report. DOT HS 809004 October 1999: 169P The edge of the beam.
