Measuring and Monitoring System of Weighing Process for Liquid Material

Abstract:

According to the characteristics and requirements of weighing process for liquid raw material, the system of data acquisition and control based on serial port communication is designed in this paper. The system adopts the modularizing distributed structure and the way of RS485 communication to ensure the reliable data transmitting between IPC (Industrial Personal Computer) and modules. Based on C++ Builder 6.0 and SQL Server 2000, the system not only implements the process control of weighing and blending, but also realizes the production data storage and management. This paper analyzes the system function structure, describes the method of communication and introduces the means of data management. The application result indicates that this system improves the production efficiency and stabilizes the production process.

• Periodical: Key Engineering Materials (Volume 455)
• Pages: 486-489
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.455.486
• Online since: December 2010
• Authors: X.C. Ku, Ji Shun Li, Wei Ma, Hong Biao Han
• Keywords: C++ Builder, Measuring, Monitoring, RS485, SQL Server, Weighing

References

[1] T. Samad, P. McLaughlin and J. Lu: Journal of Process Control, Vol. 17 (2007) No. 5, pp.191-201.

[2] R. Bai, T.Y. Chai and E.J. Ma: Journal of System Simulation, Vol. 11 (2007) No. 9, pp.2594-2598. (in Chinese).

[3] Y.Z. Fan and W.X. Jiang: Serial Communication Control for C++ Builder and RS232 (Tsinghua university press, China 2002) (in Chinese).

[4] D.M. Zhou and X.G. Su: Journal of Process Automation Instrumentation, Vol. 27 (2006) No. 3, pp.56-59. (in Chinese).

[5] C.S. Yu and X. P Wang: Database Development with C++ Builder (Postage and telegram press, China 2003) (in Chinese).
