Performance Prediction and Experimental Study of a New Electromagnetic Vibration Pump

Abstract:

A new type of small flow and high head vibration pump with electromagnetic drive was designed for the production and daily life applications in north-western region of China, where people face the problem of water shortage. The power generated by electromagnetic actuator and the deformation produced by the elasticity board module were simulated using ANSYS software. The flow and head of the vibration pump were deduced and then the correlation between the pump characteristics and material and construction were analyzed. Experiments based on sample pump were carried out and the characteristics of the pump were obtained. The fact that the test results shows that simulation of the vibration of the pump based on ANSYS can effectively predict the performance of the vibration pump. The comparison of simulation value and experimental data indicates that this method is feasible and accurate. This research will provide references for further study of the vibration pump and adequate theoretical basis for industrial production.

• Periodical: Key Engineering Materials (Volume 464)
• Pages: 279-284
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.464.279
• Online since: January 2011
• Authors: Dan Qing Yuan, He Zhang, Rui Wang, You Quan He, Jian Ping Li
• Keywords: Elasticity Board Module, Electromagnetic Actuator Mechanism, Electromagnetic Vibration Pump, Finite Element Analysis (FEA), Performance Test

References

[1] Zhu Zuchao; Hangzhou, Zhejiang University (1997).

[2] Qian Hongjun and Wei Zhangbing: Fluid Machinery. Vol. 31, No7 (2003), p.124.

[3] Sang Yimeng: Zhen Jiang, Jiangsu University (2007).

[4] Sun Mingli, Hu Renxi and Cui Hairong: ANSYS10. 0 Electromagnetics Finite Element Analysis Tutorial Example (Machinery Industry Publications, China 2007).

[5] Hsien-Tsung Chang, Chia-Yen Lee, Chih-Yung Wen etal: Microelectronics Journal. Vol. 38 (2007), p.791–799.

[6] M. Elhaj, F. Gu, A.D. Ball and A. Albarbar: Mechanical Systems and Signal Processing. Vol. 22(2008), pp.374-389.

DOI: 10.1016/j.ymssp.2007.08.003

[7] Wen Bangchun: Design of Machines and Mechanisms (Machinery Industry Publications, China 2010).

[8] Li Yinshan: Maple Material Mechanics (Machinery Industry Publications, China 2008).

[9] Zhu Junhua, Zhan Changsong: Reciprocating Pump (Machinery Industry Publications, China 1992).

[10] Xiong Youde: Strength of Materials (Materials Science Publications, China 2009).
