Study on Hardware and Software Realization of Harmonic Detection in Power System

Abstract:

This article introduces a harmonic detection device based on ARM/ DSP. This device uses DSP technology to analysis the harmonic wave in the power system by using complex sequence fast Fourier algorithm, and realizes the power system harmonic on-line detection with the strong control function of ARM module. It overcomes the inconsistency of the time sequence in communicating between DSP and ARM, and solves the synchronous sampling problem of each phase voltage for data acquisition module. In the program it mainly solves the HPI interface of data communication problem between DSP and ARM. Practical applications show that the device can rapidly and accurately detect characterization of power quality, and realize the telecommunication of the power grid data. It can detcet data accurately and reach the level of practical applications.

• Periodical: Key Engineering Materials (Volumes 467-469)
• Pages: 1973-1978
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.467-469.1973
• Online since: February 2011
• Authors: Kai Zhang, Xia Zhao, Zhi Hong Zheng
• Keywords: ARM, Digital Signal Processor (DSP), Harmonic Detection, Power Quality (PQ), Single Acquisition

References

[1] J.F. Sun, L.F. Li and K.P. Liu. The Power Quality Analysis Method Based on FFT and Wavelet Transform. Chinese Journal of Scientific Instrument, Vol. 8 (2005), pp.115-116.

[2] Volker Kuhlmann, Alastair Sinton, Mike Deve, Chris Arnold, Effects of Sampling Rate and ADC Width on the Accuracy of Amplitude and Phase Measurements in Power-Quality Monitoring, IEEE Trans, Power Delivery, Vol. 22, No. 2, (2007).

DOI: 10.1109/tpwrd.2007.893389

[3] X.B. Mao J.M. Lv. Electric Parameters of Exchange and Sampling Technology and The Hardware and Software Designing. Chinese Journal of Scientific Instrument, Vol. 22(2001), pp.195-196.

[4] Z.A. Wang, Harmonic and reactive power compensation(Mechanical industry press, Beijing 2006).

[5] K. Hao. Harmonic Detection and Treatment in Power System. China testing technology, Vol. 31 (2005), p . 64-67.

[6] Z. Xu. Harmonious Waves in Power Systems-The basic principle and method of analysis and design of filter(Mechanical industry press, Beijing 2003).

[7] L.S. Lv. Ultraharmonics in Power Systems(China Electric Power Press, Beijing 1998).

[8] M.H.J. Bollen, Understanding Power Quality Problems: Voltage Sags and Interruptions. Piscataway, NJ: IEEE Press, (2000).

[9] P. Daponte,M. Di Penta, Transient Meter: A Distributed Measurements System for Power Quality Monitoring, IEEE Trans, Power Delivery, Vol. 19, No. 2 April. (2004).

[10] The frequency and voltage level standardization technical committee. The National Standards Used Manual of Voltage 、Current 、Frequency and Power Quality (China Electric Power Press, Beijing 2001).

[11] W.Q. Hou,B. Zhang D.Y. Qiu. The Power Quality Inspection and Reactive Power Compensation Comprehensive Measurement Device Based on DSP. Chinese Journal of Scientific Instrument, Vol. 28 (2007), pp.120-127.

[12] Q.W. Zhang J.X. Xie. Detailed example of Common Module and Comprehensive System design of ARM Embedded. ( Electronic Industry Press, Beijing 2007).
